Ricardo
Ricardo ZH4105ZD
ZH4105 Series
Ricardo ZH4105ZD generator-drive diesel engine validated from Bauer Generator GFS technical datasheets. Bauer lists the engine as ZH4105ZD/56KW with 4 inline cylinders, 4.15 L displacement, 1500 rpm speed, diesel fuel, liquid cooling, and Non Emission Certified labeling.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-08-05
- Package route
- diesel generator sets
- Mechanical Output
- 62 kW
- Cylinders
- L4
- Displacement
- 4.15 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 56 | — | — |
| Standby Power | 61.6 | — | — |
Ask about Ricardo ZH4105ZD
Choose parts / service or sourcing. Your message includes this model and page link.
Ricardo ZH4105ZD overhaul & repair parts
Already running a Ricardo ZH4105ZD? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with ZH4105ZD and your selected categories included. Attach your photos there.
Ricardo ZH4105ZD generator set context
The Ricardo ZH4105ZD is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 62 kW / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Ricardo |
| Model | ZH4105ZD |
| Series | ZH4105 Series |
| Configuration | L4, generator-drive diesel |
| Cylinders | 4 |
| Displacement | 4.15 L |
| Compression Ratio | 18:1 |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
Does the ZH4105ZD run at 50 Hz or 60 Hz?
The Ricardo ZH4105ZD is rated for 50 Hz (1,500 rpm).
What fuel does the Ricardo ZH4105ZD use?
The Ricardo ZH4105ZD is a diesel generator-set engine.
What is the displacement and cylinder configuration of the ZH4105ZD?
The Ricardo ZH4105ZD is an inline-4 (4-cylinder) engine with a displacement of 4.15 L.
What is the catalog status of the Ricardo ZH4105ZD?
The Ricardo ZH4105ZD is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the ZH4105ZD?
This page links reference documents for the Ricardo ZH4105ZD. Check each document's title, model coverage, revision and rating conditions before using it for selection.
