Haifeng Machinery

SDEC 4HT4.3-G22

The SDEC 4HT4.3-G22 is a 4.3-litre inline-4 diesel engine for generator sets, rated at 76 kVA / 61 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.

Production StatusIn Production

H Series

Representative SDEC engine
Electrical output 50 Hz · 1500 RPM
Prime power56 kWe
Standby power61 kWe
Configuration
L4
Displacement
4.3 L
Fuel
Diesel

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

RatingPrimeStandby
Mechanical power kWm6268
Electrical output kWe5661
Apparent power kVA7076.3

60 Hz1800 RPM

RatingPrimeStandby
Mechanical power kWm6774
Electrical output kWe6067
Apparent power kVA7583.8

Datasheet & documents

Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.

Technical specifications

Technical Specifications

BrandSDEC
Model4HT4.3-G22
SeriesH Series
ConfigurationL4
Cylinders4
Displacement4.3 L
Fuel TypeDiesel
Ignition TypeCompression Ignition
Cooling MethodLiquid-Cooled
Emissions StandardChina National Stage III / Unregulated
Country of OriginChina

Check your engine model

The SDEC 4HT4.3-G22 is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 76 kVA / 61 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.

Other ways this model is written

4ht43g224HT4.3 G22SDEC 4HT4.3-G22H Series 4HT4.3-G22

4HT4.3-G22 repair parts

Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.

Get a parts & air-shipping quote
In-stock parts: same-day dispatch

Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.

Find the right part

Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.

Get my parts quote on WhatsApp

We’ll confirm the correct parts, stock and delivery cost before you order.

Opens WhatsApp. Attach photos in the chat.

Photos and details to send
  1. Take a clear photo of the engine nameplate.
  2. Tell us what needs repair or replacement.
  3. Send both in WhatsApp to start a fitment check.
How to read your engine nameplate
Parts reference availability

We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.

Get help with this engine

Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.

Opens WhatsApp. You can edit your message before sending.

Other ways to contact us
Scan QRHide QRHaifeng general WhatsApp chat QR codeGeneral WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team

Need help after checking the documents?

Send us the part number or describe the problem. This engine model is included in your message.

Send this model enquiry by email

Or browse Haifeng's diesel generator sets

Frequently asked questions

What is the power output of the SDEC 4HT4.3-G22?

The SDEC 4HT4.3-G22 is rated at 76 kVA standby / 70 kVA prime at 50 Hz (1,500 rpm); and 84 kVA standby / 75 kVA prime at 60 Hz (1,800 rpm).

Does the 4HT4.3-G22 run at 50 Hz or 60 Hz?

The SDEC 4HT4.3-G22 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).

What fuel does the SDEC 4HT4.3-G22 use?

The SDEC 4HT4.3-G22 is a diesel generator-set engine.

What is the displacement and cylinder configuration of the 4HT4.3-G22?

The SDEC 4HT4.3-G22 is an inline-4 (4-cylinder) engine with a displacement of 4.3 L.

What is the catalog status of the SDEC 4HT4.3-G22?

The SDEC 4HT4.3-G22 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.

Are reference documents available for the 4HT4.3-G22?

This page links reference documents for the SDEC 4HT4.3-G22. Check each document's title, model coverage, revision and rating conditions before using it for selection.
