SDEC
SDEC 4ZTAA4.1-G32
Z Series
The SDEC 4ZTAA4.1-G32 is a 4.1-litre inline-4 diesel engine for generator sets, rated at 118 kVA / 94 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 118 kVA
- Electrical Output
- 94 kWe
- Cylinders
- L4
- Displacement
- 4.1 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 95.6 | 86 | 107.5 |
| Standby Power | 104.4 | 94 | 117.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 104.4 | 94 | 117.5 |
| Standby Power | 115.6 | 104 | 130 |
Technical Specifications
| Brand | SDEC |
| Model | 4ZTAA4.1-G32 |
| Series | Z Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 4.1 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage II / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the SDEC 4ZTAA4.1-G32?
The SDEC 4ZTAA4.1-G32 is rated at 118 kVA standby / 108 kVA prime at 50 Hz (1,500 rpm); and 130 kVA standby / 118 kVA prime at 60 Hz (1,800 rpm).
Does the 4ZTAA4.1-G32 run at 50 Hz or 60 Hz?
The SDEC 4ZTAA4.1-G32 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the SDEC 4ZTAA4.1-G32 use?
The SDEC 4ZTAA4.1-G32 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4ZTAA4.1-G32?
The SDEC 4ZTAA4.1-G32 is an inline-4 (4-cylinder) engine with a displacement of 4.1 L.
Is the SDEC 4ZTAA4.1-G32 still in production?
Yes — the SDEC 4ZTAA4.1-G32 is a current production model.
Is a datasheet available for the 4ZTAA4.1-G32?
Yes — an official SDEC datasheet for the SDEC 4ZTAA4.1-G32 can be downloaded from this page.
