SDEC
SDEC SC8D280D2
D Series
The SDEC SC8D280D2 is a 8-litre inline-6 diesel engine for generator sets, rated at 230 kVA / 184 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Overhaul & repair parts- Supporting documents
- 2 documents · 1 datasheet
- Last updated
- 2026-07-24
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 230 kVA
- Electrical Output
- 184 kWe
- Cylinders
- L6
- Displacement
- 8 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 185 | 167 | 208.8 |
| Standby Power | 204 | 184 | 230 |
Ask about SDEC SC8D280D2
Choose parts / service or sourcing. Your message includes this model and page link.
SDEC SC8D280D2 overhaul & repair parts
Already running a SDEC SC8D280D2? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with SC8D280D2 and your selected categories included. Attach your photos there.
SDEC SC8D280D2 generator set context
The SDEC SC8D280D2 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 230 kVA / 184 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | SDEC |
| Model | SC8D280D2 |
| Series | D Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 8 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage II / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the SDEC SC8D280D2?
The SDEC SC8D280D2 is rated at 230 kVA standby / 209 kVA prime at 50 Hz (1,500 rpm).
Does the SC8D280D2 run at 50 Hz or 60 Hz?
The SDEC SC8D280D2 is rated for 50 Hz (1,500 rpm).
What fuel does the SDEC SC8D280D2 use?
The SDEC SC8D280D2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the SC8D280D2?
The SDEC SC8D280D2 is an inline-6 (6-cylinder) engine with a displacement of 8 L.
What is the catalog status of the SDEC SC8D280D2?
The SDEC SC8D280D2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the SC8D280D2?
This page links reference documents for the SDEC SC8D280D2. Check each document's title, model coverage, revision and rating conditions before using it for selection.
