VMAN
VMAN C03B1
The VMAN C03B1 is a 2.5-litre inline-4 diesel engine for generator sets, rated at 50 kVA / 40 kWe standby power at 1,800 RPM (60 Hz). It is a liquid-cooled engine built in China.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-08
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 50 kVA
- Electrical Output
- 40 kWe
- Cylinders
- L4
- Displacement
- 2.5 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 40 | 36 | 45 |
| Standby Power | 44 | 40 | 50 |
Ask about VMAN C03B1
Choose parts / service or sourcing. Your message includes this model and page link.
VMAN C03B1 overhaul & repair parts
Already running a VMAN C03B1? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with C03B1 and your selected categories included. Attach your photos there.
VMAN C03B1 generator set context
The VMAN C03B1 is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 50 kVA / 40 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | VMAN |
| Model | C03B1 |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 2.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the VMAN C03B1?
The VMAN C03B1 is rated at 50 kVA standby / 45 kVA prime at 60 Hz (1,800 rpm).
Does the C03B1 run at 50 Hz or 60 Hz?
The VMAN C03B1 is rated for 60 Hz (1,800 rpm).
What fuel does the VMAN C03B1 use?
The VMAN C03B1 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the C03B1?
The VMAN C03B1 is an inline-4 (4-cylinder) engine with a displacement of 2.5 L.
What is the catalog status of the VMAN C03B1?
The VMAN C03B1 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the C03B1?
This page links reference documents for the VMAN C03B1. Check each document's title, model coverage, revision and rating conditions before using it for selection.
