Volvo Penta
Volvo Penta TD720GE
Early D7 Power Generation
Volvo Penta TD720GE discontinued legacy generator-drive diesel. The 2013 Volvo Penta operator manual identifies TD720GE in the 4-7 Liter EDC4 family and gives 7.15 L displacement, six cylinders, 128 kW at 1500 rpm, and 134 kW at 1800 rpm.
Chat on WhatsApp about this engine
Opens WhatsApp with Volvo Penta TD720GE and this page link filled in.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-08-11
- Package route
- diesel generator sets
- Electrical Output
- 128 kW
- Cylinders
- L6
- Displacement
- 7.15 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 128 | — | — |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 134 | — | — |
Volvo Penta TD720GE generator set context
The Volvo Penta TD720GE is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 128 kW / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Volvo Penta |
| Model | TD720GE |
| Series | Early D7 Power Generation |
| Configuration | Inline-6, turbocharged diesel genset engine |
| Cylinders | 6 |
| Displacement | 7.15 L |
| Compression Ratio | 17.1:1 |
| Dry Weight | 750 kg |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | EPA Tier 1 / EU Stage II |
| Certifications | EPA Tier 1, EU Stage II |
| Country of Origin | Sweden |
Frequently asked questions
What is the power output of the Volvo Penta TD720GE?
The Volvo Penta TD720GE is rated at 160 kVA prime at 50 Hz (1,500 rpm); and 168 kVA prime at 60 Hz (1,800 rpm).
Does the TD720GE run at 50 Hz or 60 Hz?
The Volvo Penta TD720GE is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Volvo Penta TD720GE use?
The Volvo Penta TD720GE is a diesel generator-set engine.
What is the displacement and cylinder configuration of the TD720GE?
The Volvo Penta TD720GE is an inline-6 (6-cylinder) engine with a displacement of 7.15 L.
What emissions standard does the TD720GE meet?
The Volvo Penta TD720GE is certified to EPA Tier 1 / EU Stage II emissions standards.
Is the TD720GE still in production?
No — the Volvo Penta TD720GE is discontinued. Its specifications and datasheets remain archived here for reference.
Is a datasheet available for the TD720GE?
Yes — an official Volvo Penta datasheet for the Volvo Penta TD720GE can be downloaded from this page.
