Wandi WD287TAD58

Wandi WD287TAD58 — 28.7-litre V12 diesel engine. Find specifications, documents and parts support below.

Production StatusIn Production

Mechanical Output: 588 kW
Cylinders: V12
Displacement: 28.7 L
Rated Speed: 1,500 RPM

Estimated electrical output

Engine power × 0.90. These are estimates, not manufacturer generator ratings. Actual output depends on the alternator and operating conditions.

Frequency / duty	Engine	Estimate
Frequency and duty unverified	588 kWm	529.2 kWe

Datasheet & documents

Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.

Downloads

Datasheet
Wandi WD series — official engine technical parameters
160 KB

Source notes

Manufacturer: Wuxi Power Engineering Co., Ltd. (无锡动力工程股份有限公司), Wandi (万迪).

Official manufacturer product table, reviewed 2026-10-26.

Rated mechanical engine output 588 kW at 1500 rpm.

Published overload power 647 kW; this is not independently confirmed as ISO ESP.

Bore/stroke 138×160 mm.

Minimum specific fuel consumption 195 g/kWh; lubricating-oil consumption ≤0.67 g/kWh; exhaust temperature ≤650 C.

Source does not establish ISO PRP/ESP duty; frequency-specific prime/standby fields are unset.

No emissions certification is inferred from family marketing claims or model suffixes.

Active indicates currently listed by the manufacturer, not independent confirmation of production availability.

Source: wdpower.com · source

Official WD series datasheet, PDF p3, visually verified 2026-10-26: 12 cylinders, V layout; manufacturer net engine weight 2000 kg (converted from tonnes; no independent dry/wet qualification).

Total lubricating-oil capacity 50 L.

Total cooling-fluid capacity 155 L for the radiator-cooled configuration shown; not assumed engine-only coolant volume.

Maximum inlet resistance 6.2 kPa; maximum exhaust back pressure 6 kPa; maximum water outlet temperature 95 C; maximum oil temperature 100 C; thermostat range 72-84 C.

Electronic governing.

Unresolved specific-fuel-consumption difference: website lists 195 g/kWh, PDF lists 198 g/kWh.

Neither value supersedes the other pending manufacturer clarification.

Overall dimensions are withheld from structured engine-only fields pending confirmation of radiator/accessory scope; some published packing dimensions are smaller than overall dimensions.

Existing mechanical power is unchanged; source overload/standby labels do not establish ISO ESP or PRP.

Source: img01.71360.com · PDF

View WD287TAD58 spec image

Wandi WD287TAD58 28.7L V12 diesel generator engine specifications — Shareable spec cardWandi WD287TAD58 summary imageOpen image

Technical specifications

Technical Specifications

Brand	Wandi
Model	WD287TAD58
Series	WD
Configuration	V12
Cylinders	12
Displacement	28.7 L
Compression Ratio	15.2:1
Dry Weight	2000 kg
Fuel Type	Diesel
Country of Origin	China
