Weichai
Weichai 16M55D2900E310
M55 Series
The Weichai 16M55D2900E310 is a 88-litre V16 diesel engine for generator sets, rated at 3,263 kVA / 2,610 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Get help with this engine
Tell Haifeng whether you already own a Weichai 16M55D2900E310 engine/generator or need to source this model for a project.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 3,263 kVA
- Electrical Output
- 2,610 kWe
- Cylinders
- V16
- Displacement
- 88 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2645.6 | 2381 | 2976.3 |
| Standby Power | 2900 | 2610 | 3262.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2870 | 2583 | 3228.8 |
| Standby Power | 3150 | 2835 | 3543.8 |
Weichai 16M55D2900E310 generator set context
The Weichai 16M55D2900E310 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 3,263 kVA / 2,610 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Weichai |
| Model | 16M55D2900E310 |
| Series | M55 Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 88 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Weichai 16M55D2900E310?
The Weichai 16M55D2900E310 is rated at 3,263 kVA standby / 2,976 kVA prime at 50 Hz (1,500 rpm); and 3,544 kVA standby / 3,229 kVA prime at 60 Hz (1,800 rpm).
Does the 16M55D2900E310 run at 50 Hz or 60 Hz?
The Weichai 16M55D2900E310 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Weichai 16M55D2900E310 use?
The Weichai 16M55D2900E310 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 16M55D2900E310?
The Weichai 16M55D2900E310 is a V16 (16-cylinder) engine with a displacement of 88 L.
Is the Weichai 16M55D2900E310 still in production?
Yes — the Weichai 16M55D2900E310 is a current production model.
Is a datasheet available for the 16M55D2900E310?
Yes — an official Weichai datasheet for the Weichai 16M55D2900E310 can be downloaded from this page.
