Weichai
Weichai 16M55D2750E310
M55 Series
The Weichai 16M55D2750E310 is a 88-litre V16 diesel engine for generator sets, rated at 3,094 kVA / 2,475 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 3,094 kVA
- Electrical Output
- 2,475 kWe
- Cylinders
- V16
- Displacement
- 88 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2500 | 2250 | 2812.5 |
| Standby Power | 2750 | 2475 | 3093.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2710 | 2439 | 3048.8 |
| Standby Power | 2960 | 2664 | 3330 |
Technical Specifications
| Brand | Weichai |
| Model | 16M55D2750E310 |
| Series | M55 Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 88 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Weichai 16M55D2750E310?
The Weichai 16M55D2750E310 is rated at 3,094 kVA standby / 2,813 kVA prime at 50 Hz (1,500 rpm); and 3,330 kVA standby / 3,049 kVA prime at 60 Hz (1,800 rpm).
Does the 16M55D2750E310 run at 50 Hz or 60 Hz?
The Weichai 16M55D2750E310 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Weichai 16M55D2750E310 use?
The Weichai 16M55D2750E310 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 16M55D2750E310?
The Weichai 16M55D2750E310 is a V16 (16-cylinder) engine with a displacement of 88 L.
Is the Weichai 16M55D2750E310 still in production?
Yes — the Weichai 16M55D2750E310 is a current production model.
Is a datasheet available for the 16M55D2750E310?
Yes — an official Weichai datasheet for the Weichai 16M55D2750E310 can be downloaded from this page.
Related Engines
Compare Weichai 16M55D2750E310
Reference
- Canonical page
- /engines/weichai-16m55d2750e310
- Last database update
- 2026-05-29
- Manufacturer files
- 1 datasheet linked
