Yanmar
Yanmar 3TNM74F-NGGE
TNM F Series
Yanmar 3TNM74F-NGGE 0.993 L naturally aspirated inline-3 diesel generator engine. The page stores the 50 Hz generator rating, while Yanmar documents the family as U.S. EPA Tier 4 Final and Euro Stage V.
Overhaul & repair parts- Supporting documents
- 3 documents · 2 datasheets
- Last updated
- 2026-07-25
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 8 kVA
- Electrical Output
- 7 kWe
- Cylinders
- L3
- Displacement
- 0.993 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 7.3 | 6.6 | 8.2 |
Ask about Yanmar 3TNM74F-NGGE
Choose parts / service or sourcing. Your message includes this model and page link.
Yanmar 3TNM74F-NGGE overhaul & repair parts
Already running a Yanmar 3TNM74F-NGGE? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Reviewed part-number references
A starting point for identification. Fitment must be confirmed before ordering.
- Piston119D00-22080
Yanmar piston assembly
Fitment check: The official Yanmar category title names 3TNM74F-NGGE literally and its product record lists PISTON ASSY 119D00-22080. Confirm the complete engine serial number, installed component specification, and current Yanmar supersession before ordering.
Source: Yanmar US official online parts catalog
- Piston ring set119C10-22500
Yanmar piston ring set
Fitment check: The official Yanmar category title names 3TNM74F-NGGE literally and its product record lists RING SET, PISTON 119C10-22500. Confirm the complete engine serial number, installed component specification, and current Yanmar supersession before ordering.
Source: Yanmar US official online parts catalog
Selected references only; this is not a complete overhaul list or a stock listing.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 3TNM74F-NGGE and your selected categories included. Attach your photos there.
Yanmar 3TNM74F-NGGE generator set context
The Yanmar 3TNM74F-NGGE is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 8 kVA / 7 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Yanmar |
| Model | 3TNM74F-NGGE |
| Series | TNM F Series |
| Configuration | L3 |
| Cylinders | 3 |
| Displacement | 0.993 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Yanmar 3TNM74F-NGGE?
The Yanmar 3TNM74F-NGGE is rated at 8 kVA standby at 50 Hz (1,500 rpm).
Does the 3TNM74F-NGGE run at 50 Hz or 60 Hz?
The Yanmar 3TNM74F-NGGE is rated for 50 Hz (1,500 rpm).
What fuel does the Yanmar 3TNM74F-NGGE use?
The Yanmar 3TNM74F-NGGE is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 3TNM74F-NGGE?
The Yanmar 3TNM74F-NGGE is an inline-3 (3-cylinder) engine with a displacement of 0.993 L.
What emissions information is listed for the 3TNM74F-NGGE?
This record lists Euro Stage V for the Yanmar 3TNM74F-NGGE. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Yanmar 3TNM74F-NGGE?
The Yanmar 3TNM74F-NGGE is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 3TNM74F-NGGE?
This page links reference documents for the Yanmar 3TNM74F-NGGE. Check each document's title, model coverage, revision and rating conditions before using it for selection.
