Yanmar
Yanmar 3TNV76-HGE
TNV Series
Yanmar 3TNV76-HGE - 3-cylinder high-speed diesel engine for generator sets. 3000/3600 RPM (50Hz/60Hz). EPA Tier 2 certified.
Chat on WhatsApp about this engine
Opens WhatsApp with Yanmar 3TNV76-HGE and this page link filled in.
- Manufacturer files
- 3 datasheets
- Last updated
- 2026-06-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 19 kVA
- Electrical Output
- 15 kWe
- Cylinders
- L3
- Displacement
- 1.496 L
- Rated Speed
- 3,000 / 3,600 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz3000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 16.6 | 14.9 | 18.6 |
60 Hz3600 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 19.6 | 17.6 | 22 |
Yanmar 3TNV76-HGE generator set context
The Yanmar 3TNV76-HGE is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 19 kVA / 15 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Yanmar |
| Model | 3TNV76-HGE |
| Series | TNV Series |
| Configuration | L3 |
| Cylinders | 3 |
| Displacement | 1.496 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Yanmar 3TNV76-HGE?
The Yanmar 3TNV76-HGE is rated at 19 kVA standby at 50 Hz (3,000 rpm); and 22 kVA standby at 60 Hz (3,600 rpm).
Does the 3TNV76-HGE run at 50 Hz or 60 Hz?
The Yanmar 3TNV76-HGE is available for both 50 Hz (3,000 rpm) and 60 Hz (3,600 rpm).
What fuel does the Yanmar 3TNV76-HGE use?
The Yanmar 3TNV76-HGE is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 3TNV76-HGE?
The Yanmar 3TNV76-HGE is an inline-3 (3-cylinder) engine with a displacement of 1.496 L.
What emissions standard does the 3TNV76-HGE meet?
The Yanmar 3TNV76-HGE is certified to U.S. EPA Tier 2 emissions standards.
Is the Yanmar 3TNV76-HGE still in production?
Yes — the Yanmar 3TNV76-HGE is a current production model.
Is a datasheet available for the 3TNV76-HGE?
Yes — an official Yanmar datasheet for the Yanmar 3TNV76-HGE can be downloaded from this page.
