Yanmar
Yanmar 3TNV88-GGHWC
TNV Series
Yanmar 3TNV88-GGHWC - 3-cylinder diesel engine for generator sets with hot water cooling. EPA Tier 2 certified.
Chat on WhatsApp about this engine
Opens WhatsApp with Yanmar 3TNV88-GGHWC and this page link filled in.
- Manufacturer files
- No datasheet
- Last updated
- 2026-06-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 15 kVA
- Electrical Output
- 12 kWe
- Cylinders
- L3
- Displacement
- 1.763 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 13.2 | 11.9 | 14.9 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 16.2 | 14.6 | 18.3 |
Yanmar 3TNV88-GGHWC generator set context
The Yanmar 3TNV88-GGHWC is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 15 kVA / 12 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Yanmar |
| Model | 3TNV88-GGHWC |
| Series | TNV Series |
| Configuration | L3 |
| Cylinders | 3 |
| Displacement | 1.763 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Yanmar 3TNV88-GGHWC?
The Yanmar 3TNV88-GGHWC is rated at 15 kVA standby at 50 Hz (1,500 rpm); and 18 kVA standby at 60 Hz (1,800 rpm).
Does the 3TNV88-GGHWC run at 50 Hz or 60 Hz?
The Yanmar 3TNV88-GGHWC is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Yanmar 3TNV88-GGHWC use?
The Yanmar 3TNV88-GGHWC is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 3TNV88-GGHWC?
The Yanmar 3TNV88-GGHWC is an inline-3 (3-cylinder) engine with a displacement of 1.763 L.
What emissions standard does the 3TNV88-GGHWC meet?
The Yanmar 3TNV88-GGHWC is certified to U.S. EPA Tier 2 emissions standards.
Is the Yanmar 3TNV88-GGHWC still in production?
Yes — the Yanmar 3TNV88-GGHWC is a current production model.
