Yanmar
Yanmar 4TNV106-GGE
TNV Series
Yanmar 4TNV106-GGE is a 3.769L L4 4-cylinder diesel generator-drive engine in the TNV Series, rated at 44.5 kWe standby output at 1,500 rpm / 50 Hz. It is U.S. EPA Tier 2 emissions and built in Japan.
Overhaul & repair parts- Supporting documents
- 2 documents · 1 datasheet
- Last updated
- 2026-06-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 56 kVA
- Electrical Output
- 45 kWe
- Cylinders
- L4
- Displacement
- 3.769 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 49.4 | 44.5 | 55.6 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 58.7 | 52.8 | 66 |
Ask about Yanmar 4TNV106-GGE
Choose parts / service or sourcing. Your message includes this model and page link.
Yanmar 4TNV106-GGE overhaul & repair parts
Already running a Yanmar 4TNV106-GGE? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Reviewed part-number references
A starting point for identification. Fitment must be confirmed before ordering.
- Overhaul gasket kit723900-92730
GASKET SET
Fitment check: Match the exact Yanmar model suffix 4TNV106-GGE and confirm the complete engine serial number in the current Yanmar parts system
Source: Yanmar US official parts storefront - GASKET SET (4TNV106-GGE)
- Cylinder head gasket158560-51600
GASKET, HEAD
Fitment check: Match the exact Yanmar model suffix 4TNV106-GGE and confirm the complete engine serial number in the current Yanmar parts system
Source: Yanmar US official parts storefront - FUEL INJECTION PUMP (4TNV106-GGE)
- Engine gasketTB1207FC
GASKET, LIQUID
Fitment check: Match the exact Yanmar model suffix 4TNV106-GGE and confirm the complete engine serial number in the current Yanmar parts system
Source: Yanmar US official parts storefront - GASKET SET (4TNV106-GGE)
Selected references only; this is not a complete overhaul list or a stock listing.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 4TNV106-GGE and your selected categories included. Attach your photos there.
Yanmar 4TNV106-GGE generator set context
The Yanmar 4TNV106-GGE is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 56 kVA / 45 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Yanmar |
| Model | 4TNV106-GGE |
| Series | TNV Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3.769 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Yanmar 4TNV106-GGE?
The Yanmar 4TNV106-GGE is rated at 56 kVA standby at 50 Hz (1,500 rpm); and 66 kVA standby at 60 Hz (1,800 rpm).
Does the 4TNV106-GGE run at 50 Hz or 60 Hz?
The Yanmar 4TNV106-GGE is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Yanmar 4TNV106-GGE use?
The Yanmar 4TNV106-GGE is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4TNV106-GGE?
The Yanmar 4TNV106-GGE is an inline-4 (4-cylinder) engine with a displacement of 3.769 L.
What emissions information is listed for the 4TNV106-GGE?
This record lists U.S. EPA Tier 2 for the Yanmar 4TNV106-GGE. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Yanmar 4TNV106-GGE?
The Yanmar 4TNV106-GGE is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 4TNV106-GGE?
This page links reference documents for the Yanmar 4TNV106-GGE. Check each document's title, model coverage, revision and rating conditions before using it for selection.
