Yanmar 4TNV106T-GGE
Yanmar 4TNV106T-GGE is a 3.769L L4 4-cylinder diesel generator-drive engine in the TNV Series, rated at 50.4 kWe standby output at 1,500 rpm / 50 Hz. It is U.S. EPA Tier 2 emissions and built in Japan.
TNV Series

- Configuration
- L4
- Displacement
- 3.769 L
- Fuel
- Diesel
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| Rating | Standby |
|---|---|
| Mechanical power kWm | 56 |
| Electrical output kWe | 50.4 |
| Apparent power kVA | 63 |
60 Hz1800 RPM
| Rating | Standby |
|---|---|
| Mechanical power kWm | 66.9 |
| Electrical output kWe | 60.2 |
| Apparent power kVA | 75.3 |
Datasheet & documents
Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.
Technical specifications
Technical Specifications
| Brand | Yanmar |
| Model | 4TNV106T-GGE |
| Series | TNV Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3.769 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | Japan |
Check your engine model
The Yanmar 4TNV106T-GGE is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 63 kVA / 50 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.
Other ways this model is written
4TNV106T-GGE repair parts
Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.
Get a parts & air-shipping quoteWorldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.
Find the right part
Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.
Other parts? Add them in the chat.
Get my parts quote on WhatsAppWe’ll confirm the correct parts, stock and delivery cost before you order.
Opens WhatsApp. Attach photos in the chat.
Photos and details to send
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Part-number references
Confirm fitment against your engine serial number.
- Overhaul gasket kit723900-92740
Fitment details & source
GASKET SET
Fitment check: Match the exact Yanmar model suffix 4TNV106T-GGE and confirm the complete engine serial number in the current Yanmar parts system
Source: Yanmar US official parts storefront - GASKET SET (4TNV106T-GGE)
- Cylinder head gasket158560-51600
Fitment details & source
GASKET, HEAD
Fitment check: Match the exact Yanmar model suffix 4TNV106T-GGE and confirm the complete engine serial number in the current Yanmar parts system
Source: Yanmar US official parts storefront - FUEL INJECTION PUMP (4TNV106T-GGE)
- Engine gasket123900-42050
Fitment details & source
GASKET, WATER PUMP
Fitment check: Match the exact Yanmar model suffix 4TNV106T-GGE and confirm the complete engine serial number in the current Yanmar parts system
Source: Yanmar US official parts storefront - COOLING WATER SYSTEM (4TNV106T-GGE)
Get help with this engine
Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.
Other ways to contact us
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamNeed help after checking the documents?
Send us the part number or describe the problem. This engine model is included in your message.
Send this model enquiry by emailOr browse Haifeng's diesel generator sets
Frequently asked questions
What is the power output of the Yanmar 4TNV106T-GGE?
The Yanmar 4TNV106T-GGE is rated at 63 kVA standby at 50 Hz (1,500 rpm); and 75 kVA standby at 60 Hz (1,800 rpm).
Does the 4TNV106T-GGE run at 50 Hz or 60 Hz?
The Yanmar 4TNV106T-GGE is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Yanmar 4TNV106T-GGE use?
The Yanmar 4TNV106T-GGE is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4TNV106T-GGE?
The Yanmar 4TNV106T-GGE is an inline-4 (4-cylinder) engine with a displacement of 3.769 L.
What emissions information is listed for the 4TNV106T-GGE?
This record lists U.S. EPA Tier 2 for the Yanmar 4TNV106T-GGE. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Yanmar 4TNV106T-GGE?
The Yanmar 4TNV106T-GGE is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 4TNV106T-GGE?
This page links reference documents for the Yanmar 4TNV106T-GGE. Check each document's title, model coverage, revision and rating conditions before using it for selection.
