Yanmar 4TNV84T-GGE

Yanmar 4TNV84T-GGE is a 2.344L L4 4-cylinder diesel generator-drive engine in the TNV Series, rated at 18.9 kWe standby output at 1,500 rpm / 50 Hz. It is U.S. EPA Tier 2 emissions and built in Japan.

Production StatusIn Production

TNV Series

Representative Yanmar engine
Electrical output 50 Hz · 1500 RPM
Standby power18.9 kWe
Configuration
L4
Displacement
2.344 L
Fuel
Diesel

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

RatingStandby
Mechanical power kWm21
Electrical output kWe18.9
Apparent power kVA23.6

60 Hz1800 RPM

RatingStandby
Mechanical power kWm26.8
Electrical output kWe24.1
Apparent power kVA30.1

Datasheet & documents

Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.

View 4TNV84T-GGE spec image
Shareable spec cardYanmar 4TNV84T-GGE summary imageOpen image
Yanmar 4TNV84T-GGE 2.344L L4 diesel generator engine — 24 kVA standby specifications

Technical specifications

Technical Specifications

BrandYanmar
Model4TNV84T-GGE
SeriesTNV Series
ConfigurationL4
Cylinders4
Displacement2.344 L
Fuel TypeDiesel
Ignition TypeCompression Ignition
Cooling MethodLiquid-Cooled
Emissions StandardU.S. EPA Tier 2
Country of OriginJapan

Check your engine model

The Yanmar 4TNV84T-GGE is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 24 kVA / 19 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.

Other ways this model is written

4tnv84tgge4TNV84T GGEYanmar 4TNV84T-GGETNV Series 4TNV84T-GGE

4TNV84T-GGE repair parts

Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.

Get a parts & air-shipping quote
In-stock parts: same-day dispatch

Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.

Find the right part

Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.

Which parts do you need?

Other parts? Add them in the chat.

Get my parts quote on WhatsApp

We’ll confirm the correct parts, stock and delivery cost before you order.

Opens WhatsApp. Attach photos in the chat.

Photos and details to send
  1. Take a clear photo of the engine nameplate.
  2. Tell us what needs repair or replacement.
  3. Send both in WhatsApp to start a fitment check.
How to read your engine nameplate

Part-number references

Confirm fitment against your engine serial number.

  • Overhaul gasket kit729508-92630
    Fitment details & source

    GASKET SET

    Fitment check: Match the exact Yanmar model suffix 4TNV84T-GGE and confirm the complete engine serial number in the current Yanmar parts system

    Source: Yanmar US official parts storefront - GASKET SET (4TNV84T-GGE)

  • Cylinder head gasket158552-51600
    Fitment details & source

    GASKET, HEAD

    Fitment check: Match the exact Yanmar model suffix 4TNV84T-GGE and confirm the complete engine serial number in the current Yanmar parts system

    Source: Yanmar US official parts storefront - FUEL INJECTION PUMP(INNER PARTS) (4TNV84T-GGE)

  • Engine gasket129508-18080
    Fitment details & source

    GASKET, TURBINE IN

    Fitment check: Match the exact Yanmar model suffix 4TNV84T-GGE and confirm the complete engine serial number in the current Yanmar parts system

    Source: Yanmar US official parts storefront - GASKET SET (4TNV84T-GGE)

Get help with this engine

Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.

Opens WhatsApp. You can edit your message before sending.

Other ways to contact us
Scan QRHide QRHaifeng general WhatsApp chat QR codeGeneral WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team

Need help after checking the documents?

Send us the part number or describe the problem. This engine model is included in your message.

Send this model enquiry by email

Or browse Haifeng's diesel generator sets

Frequently asked questions

What is the power output of the Yanmar 4TNV84T-GGE?

The Yanmar 4TNV84T-GGE is rated at 24 kVA standby at 50 Hz (1,500 rpm); and 30 kVA standby at 60 Hz (1,800 rpm).

Does the 4TNV84T-GGE run at 50 Hz or 60 Hz?

The Yanmar 4TNV84T-GGE is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).

What fuel does the Yanmar 4TNV84T-GGE use?

The Yanmar 4TNV84T-GGE is a diesel generator-set engine.

What is the displacement and cylinder configuration of the 4TNV84T-GGE?

The Yanmar 4TNV84T-GGE is an inline-4 (4-cylinder) engine with a displacement of 2.344 L.

What emissions information is listed for the 4TNV84T-GGE?

This record lists U.S. EPA Tier 2 for the Yanmar 4TNV84T-GGE. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.

What is the catalog status of the Yanmar 4TNV84T-GGE?

The Yanmar 4TNV84T-GGE is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.

Are reference documents available for the 4TNV84T-GGE?

This page links reference documents for the Yanmar 4TNV84T-GGE. Check each document's title, model coverage, revision and rating conditions before using it for selection.
