Haifeng Machinery

Yanmar 4TNV84T-GGFC

Yanmar 4TNV84T-GGFC - 4-cylinder turbocharged diesel engine for fire pump applications. EPA Tier 2 certified.

Production StatusIn Production

TNV Series

Representative Yanmar engine
Electrical output 50 Hz · 1500 RPM
Standby power18.9 kWe
Configuration
L4
Displacement
2.344 L
Fuel
Diesel

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

RatingStandby
Mechanical power kWm21
Electrical output kWe18.9
Apparent power kVA23.6

60 Hz1800 RPM

RatingStandby
Mechanical power kWm26.8
Electrical output kWe24.1
Apparent power kVA30.1

Datasheet & documents

Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.

View 4TNV84T-GGFC spec image
Shareable spec cardYanmar 4TNV84T-GGFC summary imageOpen image
Yanmar 4TNV84T-GGFC 2.344L L4 diesel generator engine — 24 kVA standby specifications

Technical specifications

Technical Specifications

BrandYanmar
Model4TNV84T-GGFC
SeriesTNV Series
ConfigurationL4
Cylinders4
Displacement2.344 L
Fuel TypeDiesel
Ignition TypeCompression Ignition
Cooling MethodLiquid-Cooled
Emissions StandardU.S. EPA Tier 2
Country of OriginJapan

Check your engine model

The Yanmar 4TNV84T-GGFC is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 24 kVA / 19 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.

Other ways this model is written

4tnv84tggfc4TNV84T GGFCYanmar 4TNV84T-GGFCTNV Series 4TNV84T-GGFC

4TNV84T-GGFC repair parts

Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.

Get a parts & air-shipping quote
In-stock parts: same-day dispatch

Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.

Find the right part

Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.

Get my parts quote on WhatsApp

We’ll confirm the correct parts, stock and delivery cost before you order.

Opens WhatsApp. Attach photos in the chat.

Photos and details to send
  1. Take a clear photo of the engine nameplate.
  2. Tell us what needs repair or replacement.
  3. Send both in WhatsApp to start a fitment check.
How to read your engine nameplate
Parts reference availability

We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.

Get help with this engine

Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.

Opens WhatsApp. You can edit your message before sending.

Other ways to contact us
Scan QRHide QRHaifeng general WhatsApp chat QR codeGeneral WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team

Need help after checking the documents?

Send us the part number or describe the problem. This engine model is included in your message.

Send this model enquiry by email

Or browse Haifeng's diesel generator sets

Frequently asked questions

What is the power output of the Yanmar 4TNV84T-GGFC?

The Yanmar 4TNV84T-GGFC is rated at 24 kVA standby at 50 Hz (1,500 rpm); and 30 kVA standby at 60 Hz (1,800 rpm).

Does the 4TNV84T-GGFC run at 50 Hz or 60 Hz?

The Yanmar 4TNV84T-GGFC is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).

What fuel does the Yanmar 4TNV84T-GGFC use?

The Yanmar 4TNV84T-GGFC is a diesel generator-set engine.

What is the displacement and cylinder configuration of the 4TNV84T-GGFC?

The Yanmar 4TNV84T-GGFC is an inline-4 (4-cylinder) engine with a displacement of 2.344 L.

What emissions information is listed for the 4TNV84T-GGFC?

This record lists U.S. EPA Tier 2 for the Yanmar 4TNV84T-GGFC. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.

What is the catalog status of the Yanmar 4TNV84T-GGFC?

The Yanmar 4TNV84T-GGFC is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.

Are reference documents available for the 4TNV84T-GGFC?

This page links reference documents for the Yanmar 4TNV84T-GGFC. Check each document's title, model coverage, revision and rating conditions before using it for selection.
