Yanmar
Yanmar 4TNV88-BGGES
TNV Series
Yanmar 4TNV88-BGGES is a 2.351L L4 4-cylinder diesel generator-drive engine in the TNV Series, rated at 16.2 kWe standby output at 1,500 rpm / 50 Hz. It is U.S. EPA Tier 3 emissions and built in Japan.
- Standby Power · 50 Hz
- 20 kVA
- Electrical Output
- 16 kWe
- Cylinders
- L4
- Displacement
- 2.351 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 18 | 16.2 | 20.2 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 21.6 | 19.4 | 24.2 |
Technical Specifications
| Brand | Yanmar |
| Model | 4TNV88-BGGES |
| Series | TNV Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 2.351 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 3 |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Yanmar 4TNV88-BGGES?
The Yanmar 4TNV88-BGGES is rated at 20 kVA standby at 50 Hz (1,500 rpm); and 24 kVA standby at 60 Hz (1,800 rpm).
Does the 4TNV88-BGGES run at 50 Hz or 60 Hz?
The Yanmar 4TNV88-BGGES is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Yanmar 4TNV88-BGGES use?
The Yanmar 4TNV88-BGGES is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4TNV88-BGGES?
The Yanmar 4TNV88-BGGES is an inline-4 (4-cylinder) engine with a displacement of 2.351 L.
What emissions standard does the 4TNV88-BGGES meet?
The Yanmar 4TNV88-BGGES is certified to U.S. EPA Tier 3 emissions standards.
Is the Yanmar 4TNV88-BGGES still in production?
Yes — the Yanmar 4TNV88-BGGES is a current production model.
Is a datasheet available for the 4TNV88-BGGES?
Yes — an official Yanmar datasheet for the Yanmar 4TNV88-BGGES can be downloaded from this page.
