Yanmar
Yanmar 4TNV98-GGECC
TNV Series
Yanmar 4TNV98-GGECC - 4-cylinder diesel engine for generator sets with commercial cooling configuration. EPA Tier 2 certified.
- Standby Power · 50 Hz
- 38 kVA
- Electrical Output
- 31 kWe
- Cylinders
- L4
- Displacement
- 3.119 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 34.1 | 30.7 | 38.4 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 40.8 | 36.7 | 45.9 |
Technical Specifications
| Brand | Yanmar |
| Model | 4TNV98-GGECC |
| Series | TNV Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3.119 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Yanmar 4TNV98-GGECC?
The Yanmar 4TNV98-GGECC is rated at 38 kVA standby at 50 Hz (1,500 rpm); and 46 kVA standby at 60 Hz (1,800 rpm).
Does the 4TNV98-GGECC run at 50 Hz or 60 Hz?
The Yanmar 4TNV98-GGECC is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Yanmar 4TNV98-GGECC use?
The Yanmar 4TNV98-GGECC is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4TNV98-GGECC?
The Yanmar 4TNV98-GGECC is an inline-4 (4-cylinder) engine with a displacement of 3.119 L.
What emissions standard does the 4TNV98-GGECC meet?
The Yanmar 4TNV98-GGECC is certified to U.S. EPA Tier 2 emissions standards.
Is the Yanmar 4TNV98-GGECC still in production?
Yes — the Yanmar 4TNV98-GGECC is a current production model.
Is a datasheet available for the 4TNV98-GGECC?
Yes — an official Yanmar datasheet for the Yanmar 4TNV98-GGECC can be downloaded from this page.
