Yanmar
Yanmar 4TNV98C-GGE
TNV Common Rail Series
Yanmar 4TNV98C-GGE 3.319 L naturally aspirated common-rail diesel engine for generator sets. At 1800 RPM, Yanmar publishes 34.1 kWe prime and 37.5 kWe standby. Euro Stage V and U.S. EPA Final Tier 4.
Chat on WhatsApp about this engine
Opens WhatsApp with Yanmar 4TNV98C-GGE and this page link filled in.
- Manufacturer files
- 3 datasheets
- Last updated
- 2026-07-25
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 47 kVA
- Electrical Output
- 38 kWe
- Cylinders
- L4
- Displacement
- 3.319 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 37.7 | 34.1 | 42.6 |
| Standby Power | 41.6 | 37.5 | 46.9 |
Yanmar 4TNV98C-GGE generator set context
The Yanmar 4TNV98C-GGE is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 47 kVA / 38 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Yanmar |
| Model | 4TNV98C-GGE |
| Series | TNV Common Rail Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3.319 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V / U.S. EPA Final Tier 4 |
| Certifications | Euro Stage V, U.S. EPA Final Tier 4 |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Yanmar 4TNV98C-GGE?
The Yanmar 4TNV98C-GGE is rated at 47 kVA standby / 43 kVA prime at 60 Hz (1,800 rpm).
Does the 4TNV98C-GGE run at 50 Hz or 60 Hz?
The Yanmar 4TNV98C-GGE is rated for 60 Hz (1,800 rpm).
What fuel does the Yanmar 4TNV98C-GGE use?
The Yanmar 4TNV98C-GGE is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4TNV98C-GGE?
The Yanmar 4TNV98C-GGE is an inline-4 (4-cylinder) engine with a displacement of 3.319 L.
What emissions standard does the 4TNV98C-GGE meet?
The Yanmar 4TNV98C-GGE is certified to Euro Stage V / U.S. EPA Final Tier 4 emissions standards.
Is the Yanmar 4TNV98C-GGE still in production?
Yes — the Yanmar 4TNV98C-GGE is a current production model.
Is a datasheet available for the 4TNV98C-GGE?
Yes — an official Yanmar datasheet for the Yanmar 4TNV98C-GGE can be downloaded from this page.
