Yanmar
Yanmar 4TNV98T-GGECC
TNV Series
Yanmar 4TNV98T-GGECC - 4-cylinder turbocharged diesel engine for generator sets with commercial cooling configuration. EPA Tier 2 certified.
Overhaul & repair parts- Supporting documents
- 2 documents · 1 datasheet
- Last updated
- 2026-06-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 47 kVA
- Electrical Output
- 37 kWe
- Cylinders
- L4
- Displacement
- 3.119 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 41.4 | 37.3 | 46.6 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 50.1 | 45.1 | 56.4 |
Ask about Yanmar 4TNV98T-GGECC
Choose parts / service or sourcing. Your message includes this model and page link.
Yanmar 4TNV98T-GGECC overhaul & repair parts
Already running a Yanmar 4TNV98T-GGECC? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 4TNV98T-GGECC and your selected categories included. Attach your photos there.
Yanmar 4TNV98T-GGECC generator set context
The Yanmar 4TNV98T-GGECC is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 47 kVA / 37 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Yanmar |
| Model | 4TNV98T-GGECC |
| Series | TNV Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3.119 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Yanmar 4TNV98T-GGECC?
The Yanmar 4TNV98T-GGECC is rated at 47 kVA standby at 50 Hz (1,500 rpm); and 56 kVA standby at 60 Hz (1,800 rpm).
Does the 4TNV98T-GGECC run at 50 Hz or 60 Hz?
The Yanmar 4TNV98T-GGECC is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Yanmar 4TNV98T-GGECC use?
The Yanmar 4TNV98T-GGECC is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4TNV98T-GGECC?
The Yanmar 4TNV98T-GGECC is an inline-4 (4-cylinder) engine with a displacement of 3.119 L.
What emissions information is listed for the 4TNV98T-GGECC?
This record lists U.S. EPA Tier 2 for the Yanmar 4TNV98T-GGECC. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Yanmar 4TNV98T-GGECC?
The Yanmar 4TNV98T-GGECC is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 4TNV98T-GGECC?
This page links reference documents for the Yanmar 4TNV98T-GGECC. Check each document's title, model coverage, revision and rating conditions before using it for selection.
