Yuchai
Yuchai YC16VC4200-D30
16VC
The Yuchai YC16VC4200-D30 is a 105.558-litre V16 diesel engine for generator sets, rated at 3,500 kVA / 2,800 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 3,500 kVA
- Electrical Output
- 2,800 kWe
- Cylinders
- V16
- Displacement
- 105.558 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2777.8 | 2500 | 3125 |
| Standby Power | 3111.1 | 2800 | 3500 |
Technical Specifications
| Brand | Yuchai |
| Model | YC16VC4200-D30 |
| Series | 16VC |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 105.558 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Yuchai YC16VC4200-D30?
The Yuchai YC16VC4200-D30 is rated at 3,500 kVA standby / 3,125 kVA prime at 50 Hz (1,500 rpm).
Does the YC16VC4200-D30 run at 50 Hz or 60 Hz?
The Yuchai YC16VC4200-D30 is rated for 50 Hz (1,500 rpm).
What fuel does the Yuchai YC16VC4200-D30 use?
The Yuchai YC16VC4200-D30 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the YC16VC4200-D30?
The Yuchai YC16VC4200-D30 is a V16 (16-cylinder) engine with a displacement of 105.558 L.
Is the Yuchai YC16VC4200-D30 still in production?
Yes — the Yuchai YC16VC4200-D30 is a current production model.
Related Engines
Compare Yuchai YC16VC4200-D30
Reference
- Canonical page
- /engines/yuchai-yc16vc4200-d30
- Last database update
- 2026-05-29
- Manufacturer files
- No datasheet linked yet
