Yuchai
Yuchai YC16VTD1680N-D30
The Yuchai YC16VTD1680N-D30 is a 52.26-litre V16 natural gas engine for generator sets, rated at 1,250 kVA / 1,000 kWe prime power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Overhaul & repair parts- Manufacturer files
- No datasheet
- Last updated
- 2026-06-08
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 1,250 kVA
- Electrical Output
- 1,000 kWe
- Cylinders
- V16
- Displacement
- 52.26 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1120 | 1000 | 1250 |
Ask about Yuchai YC16VTD1680N-D30
Choose parts / service or sourcing. Your message includes this model and page link.
Yuchai YC16VTD1680N-D30 overhaul & repair parts
Already running a Yuchai YC16VTD1680N-D30? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with YC16VTD1680N-D30 and your selected categories included. Attach your photos there.
Yuchai YC16VTD1680N-D30 generator set context
The Yuchai YC16VTD1680N-D30 is listed here as a natural gas generator-drive engine for 50 Hz generator sets, with a headline 1,250 kVA / 1,000 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Yuchai |
| Model | YC16VTD1680N-D30 |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 52.26 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Yuchai YC16VTD1680N-D30?
The Yuchai YC16VTD1680N-D30 is rated at 1,250 kVA prime at 50 Hz (1,500 rpm).
Does the YC16VTD1680N-D30 run at 50 Hz or 60 Hz?
The Yuchai YC16VTD1680N-D30 is rated for 50 Hz (1,500 rpm).
What fuel does the Yuchai YC16VTD1680N-D30 use?
The Yuchai YC16VTD1680N-D30 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the YC16VTD1680N-D30?
The Yuchai YC16VTD1680N-D30 is a V16 (16-cylinder) engine with a displacement of 52.26 L.
What is the catalog status of the Yuchai YC16VTD1680N-D30?
The Yuchai YC16VTD1680N-D30 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
