Yuchai
Yuchai YC16VTD2270-D32
16VTD
The Yuchai YC16VTD2270-D32 is a 52.26-litre V16 diesel engine for generator sets, rated at 1,875 kVA / 1,500 kWe standby power at 1,800 RPM (60 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 60 Hz
- 1,875 kVA
- Electrical Output
- 1,500 kWe
- Cylinders
- V16
- Displacement
- 52.26 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1500 | 1350 | 1687.5 |
| Standby Power | 1666.7 | 1500 | 1875 |
Technical Specifications
| Brand | Yuchai |
| Model | YC16VTD2270-D32 |
| Series | 16VTD |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 52.26 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Yuchai YC16VTD2270-D32?
The Yuchai YC16VTD2270-D32 is rated at 1,875 kVA standby / 1,688 kVA prime at 60 Hz (1,800 rpm).
Does the YC16VTD2270-D32 run at 50 Hz or 60 Hz?
The Yuchai YC16VTD2270-D32 is rated for 60 Hz (1,800 rpm).
What fuel does the Yuchai YC16VTD2270-D32 use?
The Yuchai YC16VTD2270-D32 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the YC16VTD2270-D32?
The Yuchai YC16VTD2270-D32 is a V16 (16-cylinder) engine with a displacement of 52.26 L.
Is the Yuchai YC16VTD2270-D32 still in production?
Yes — the Yuchai YC16VTD2270-D32 is a current production model.
Related Engines
Compare Yuchai YC16VTD2270-D32
Reference
- Canonical page
- /engines/yuchai-yc16vtd2270-d32
- Last database update
- 2026-05-29
- Manufacturer files
- No datasheet linked yet
