Yuchai YC16VTD2270-D30 Generator Engine Specs
16VTD
The Yuchai YC16VTD2270-D30 is a 52.26 L V16 diesel generator engine from the 16VTD series. It is listed for 50 Hz high-power generator sets at 1,350 kWe / 1,687.5 kVA prime and 1,500 kWe / 1,875 kVA standby, with China Stage III / unregulated-market context and an official Yuchai spec sheet linked.
Overhaul & repair parts- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-07-12
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,875 kVA
- Electrical Output
- 1,500 kWe
- Cylinders
- V16
- Displacement
- 52.26 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1500 | 1350 | 1687.5 |
| Standby Power | 1666.7 | 1500 | 1875 |
Ask about Yuchai YC16VTD2270-D30
Choose parts / service or sourcing. Your message includes this model and page link.
Yuchai YC16VTD2270-D30 overhaul & repair parts
Already running a Yuchai YC16VTD2270-D30? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with YC16VTD2270-D30 and your selected categories included. Attach your photos there.
Yuchai YC16VTD2270-D30 generator set context
The Yuchai YC16VTD2270-D30 is a 52.26 L V16 diesel generator engine from the 16VTD series. It is listed for 50 Hz high-power generator sets at 1,350 kWe / 1,687.5 kVA prime and 1,500 kWe / 1,875 kVA standby, with China Stage III / unregulated-market context and an official Yuchai spec sheet linked.
Also searched as
Technical reference links
Review a 1,500 kWe Yuchai generator package
For high-power 50 Hz diesel projects, Haifeng Machinery can review the YC16VTD2270-D30 rating, alternator match, cooling package, controls and compliance needs.
Technical Specifications
| Brand | Yuchai |
| Model | YC16VTD2270-D30 |
| Series | 16VTD |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 52.26 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Yuchai YC16VTD2270-D30?
The Yuchai YC16VTD2270-D30 is rated at 1,875 kVA standby / 1,688 kVA prime at 50 Hz (1,500 rpm).
Does the YC16VTD2270-D30 run at 50 Hz or 60 Hz?
The Yuchai YC16VTD2270-D30 is rated for 50 Hz (1,500 rpm).
What fuel does the Yuchai YC16VTD2270-D30 use?
The Yuchai YC16VTD2270-D30 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the YC16VTD2270-D30?
The Yuchai YC16VTD2270-D30 is a V16 (16-cylinder) engine with a displacement of 52.26 L.
What is the catalog status of the Yuchai YC16VTD2270-D30?
The Yuchai YC16VTD2270-D30 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the YC16VTD2270-D30?
This page links reference documents for the Yuchai YC16VTD2270-D30. Check each document's title, model coverage, revision and rating conditions before using it for selection.
