Yuchai
Yuchai YC4A205-D32
4A
The Yuchai YC4A205-D32 is a 4.837-litre inline-4 diesel engine for generator sets, rated at 165 kVA / 132 kWe standby power at 1,800 RPM (60 Hz). It is a liquid-cooled engine built in China.
Overhaul & repair parts- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 165 kVA
- Electrical Output
- 132 kWe
- Cylinders
- L4
- Displacement
- 4.837 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 133.3 | 120 | 150 |
| Standby Power | 146.7 | 132 | 165 |
Ask about Yuchai YC4A205-D32
Choose parts / service or sourcing. Your message includes this model and page link.
Yuchai YC4A205-D32 overhaul & repair parts
Already running a Yuchai YC4A205-D32? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with YC4A205-D32 and your selected categories included. Attach your photos there.
Yuchai YC4A205-D32 generator set context
The Yuchai YC4A205-D32 is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 165 kVA / 132 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Yuchai |
| Model | YC4A205-D32 |
| Series | 4A |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 4.837 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Yuchai YC4A205-D32?
The Yuchai YC4A205-D32 is rated at 165 kVA standby / 150 kVA prime at 60 Hz (1,800 rpm).
Does the YC4A205-D32 run at 50 Hz or 60 Hz?
The Yuchai YC4A205-D32 is rated for 60 Hz (1,800 rpm).
What fuel does the Yuchai YC4A205-D32 use?
The Yuchai YC4A205-D32 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the YC4A205-D32?
The Yuchai YC4A205-D32 is an inline-4 (4-cylinder) engine with a displacement of 4.837 L.
What is the catalog status of the Yuchai YC4A205-D32?
The Yuchai YC4A205-D32 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the YC4A205-D32?
This page links reference documents for the Yuchai YC4A205-D32. Check each document's title, model coverage, revision and rating conditions before using it for selection.
