Yuchai
Yuchai YC6C1660-D30
6C
The Yuchai YC6C1660-D30 is a 39.584-litre inline-6 diesel engine for generator sets, rated at 1,375 kVA / 1,100 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Get help with this engine
Tell Haifeng whether you already own a Yuchai YC6C1660-D30 engine/generator or need to source this model for a project.
- Manufacturer files
- 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,375 kVA
- Electrical Output
- 1,100 kWe
- Cylinders
- L6
- Displacement
- 39.584 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1111.1 | 1000 | 1250 |
| Standby Power | 1222.2 | 1100 | 1375 |
Yuchai YC6C1660-D30 generator set context
The Yuchai YC6C1660-D30 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 1,375 kVA / 1,100 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Yuchai |
| Model | YC6C1660-D30 |
| Series | 6C |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 39.584 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Yuchai YC6C1660-D30?
The Yuchai YC6C1660-D30 is rated at 1,375 kVA standby / 1,250 kVA prime at 50 Hz (1,500 rpm).
Does the YC6C1660-D30 run at 50 Hz or 60 Hz?
The Yuchai YC6C1660-D30 is rated for 50 Hz (1,500 rpm).
What fuel does the Yuchai YC6C1660-D30 use?
The Yuchai YC6C1660-D30 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the YC6C1660-D30?
The Yuchai YC6C1660-D30 is an inline-6 (6-cylinder) engine with a displacement of 39.584 L.
Is the Yuchai YC6C1660-D30 still in production?
Yes — the Yuchai YC6C1660-D30 is a current production model.
Is a datasheet available for the YC6C1660-D30?
Yes — an official Yuchai datasheet for the Yuchai YC6C1660-D30 can be downloaded from this page.
