Yuchai
Yuchai YC6MK420L-D20
6MK
The Yuchai YC6MK420L-D20 is a 10.338-litre inline-6 diesel engine for generator sets, rated at 350 kVA / 280 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Overhaul & repair parts- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 350 kVA
- Electrical Output
- 280 kWe
- Cylinders
- L6
- Displacement
- 10.338 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 277.8 | 250 | 312.5 |
| Standby Power | 311.1 | 280 | 350 |
Ask about Yuchai YC6MK420L-D20
Choose parts / service or sourcing. Your message includes this model and page link.
Yuchai YC6MK420L-D20 overhaul & repair parts
Already running a Yuchai YC6MK420L-D20? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with YC6MK420L-D20 and your selected categories included. Attach your photos there.
Yuchai YC6MK420L-D20 generator set context
The Yuchai YC6MK420L-D20 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 350 kVA / 280 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Yuchai |
| Model | YC6MK420L-D20 |
| Series | 6MK |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 10.338 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage II / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Yuchai YC6MK420L-D20?
The Yuchai YC6MK420L-D20 is rated at 350 kVA standby / 313 kVA prime at 50 Hz (1,500 rpm).
Does the YC6MK420L-D20 run at 50 Hz or 60 Hz?
The Yuchai YC6MK420L-D20 is rated for 50 Hz (1,500 rpm).
What fuel does the Yuchai YC6MK420L-D20 use?
The Yuchai YC6MK420L-D20 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the YC6MK420L-D20?
The Yuchai YC6MK420L-D20 is an inline-6 (6-cylinder) engine with a displacement of 10.338 L.
What is the catalog status of the Yuchai YC6MK420L-D20?
The Yuchai YC6MK420L-D20 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the YC6MK420L-D20?
This page links reference documents for the Yuchai YC6MK420L-D20. Check each document's title, model coverage, revision and rating conditions before using it for selection.
