Yuchai
Yuchai YCD4D33H6-140
Yuchai YCD4D33H6-140. Rated engine power 95 kW and standby engine power 105 kW at 1500 rpm. Supplied workbook 玉柴动力T3参数.xlsx, sheet YCD4D33H8(V42), model cell D6, rating cells D23, D24, D44. H6 exact model identity and 95/105 kW ratings are corroborated by the Guangxi Yuchai Machinery Co., Ltd. audited manufacturer storefront listing, YCD105GF row in the 50 Hz table: https://yuchai.en.made-in-china.com/product/NdSAoYhTnKRU/China-50Hz-Yuchai-Yc138GF1-Diesel-Electric-Generator-Genset.html. Workbook sheet title says H8 while its model cell says H6; the exact model cell and second-source model agree, so H6 is retained. Matched genset output 75 kW (separate from engine output). Rated engine power is not silently classified as ISO prime. No emissions certification inferred. Production status is unknown. Discontinued is the user-authorized catalogue classification, not manufacturer-confirmed cessation; no production-end year is asserted.
Need parts or a replacement for YCD4D33H6-140?
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team- Supporting documents
- No documents linked
- Last updated
- 2026-10-21
- Package route
- diesel generator sets
- Mechanical Output
- 105 kW
- Cylinders
- L4
- Displacement
- 4.2 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 105 | — | — |
Estimated rating: 94.5 kWe (105 kW × 0.90) · 50 Hz · standby
Planning estimate, not a manufacturer generator rating. Confirm the alternator, engine speed and operating conditions.
Yuchai YCD4D33H6-140 overhaul & repair parts
Need help identifying a part for your YCD4D33H6-140?
Share your nameplate, parts list and destination for a quote.
Identify my part on WhatsAppAvailability and earliest dispatch confirmed for your enquiry.
Opens WhatsApp. Attach photos in the chat.
What to send for a fitment check
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Illustrations only — not a model-specific kit or stock confirmation.
View YCD4D33H6-140 spec image
Yuchai YCD4D33H6-140 generator set context
The Yuchai YCD4D33H6-140 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 105 kW / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Model name formats
Technical Specifications
| Brand | Yuchai |
| Model | YCD4D33H6-140 |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 4.2 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
Frequently asked questions
Does the YCD4D33H6-140 run at 50 Hz or 60 Hz?
The Yuchai YCD4D33H6-140 is rated for 50 Hz (1,500 rpm).
What fuel does the Yuchai YCD4D33H6-140 use?
The Yuchai YCD4D33H6-140 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the YCD4D33H6-140?
The Yuchai YCD4D33H6-140 is an inline-4 (4-cylinder) engine with a displacement of 4.2 L.
Is the YCD4D33H6-140 still in production?
No — the Yuchai YCD4D33H6-140 is discontinued. Its specifications and datasheets remain archived here for reference.
