Yuchai
Yuchai YCD6Q23H8-225
Source-checked against supplied Yuchai workbook 玉柴动力T3参数.xlsx, sheet YCD6Q23H8(V75): 1800 rpm: rated engine 150 kW, standby engine 165 kW at 1800 rpm; matched genset 常用：120 / 备用：130 kW (model cell E6; rating cells E23, E24, E44). Engine rated power is labelled 额定 in the source, not explicitly ISO prime duty. Catalogue power_kw is the highest listed rated engine output. All calibration variants are retained here; frequency-specific prime/standby/electrical fields remain blank because the workbook does not explicitly specify frequency or ISO prime duty. No emissions certification inferred from workbook title. Production status is unknown. Discontinued is the user-authorized catalogue classification (2026-10-21 import), not manufacturer-confirmed cessation; no production-end year is asserted.
Need parts or a replacement for YCD6Q23H8-225?
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team- Supporting documents
- No documents linked
- Last updated
- 2026-10-21
- Package route
- diesel generator sets
- Mechanical Output
- 150 kW
- Cylinders
- L6
- Displacement
- 7.5 L
- Rated Speed
- 1,500 RPM
Estimated rating: 135 kWe (150 kW × 0.90) · Frequency and duty unverified
Planning estimate, not a manufacturer generator rating. Confirm the alternator, engine speed and operating conditions.
Yuchai YCD6Q23H8-225 overhaul & repair parts
Need help identifying a part for your YCD6Q23H8-225?
Share your nameplate, parts list and destination for a quote.
Identify my part on WhatsAppAvailability and earliest dispatch confirmed for your enquiry.
Opens WhatsApp. Attach photos in the chat.
What to send for a fitment check
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Illustrations only — not a model-specific kit or stock confirmation.
View YCD6Q23H8-225 spec image
Yuchai YCD6Q23H8-225 generator set context
The Yuchai YCD6Q23H8-225 is listed here as a diesel generator-drive engine for applications whose frequency must be verified, with a headline 150 kW / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Model name formats
Technical Specifications
| Brand | Yuchai |
| Model | YCD6Q23H8-225 |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
Frequently asked questions
What fuel does the Yuchai YCD6Q23H8-225 use?
The Yuchai YCD6Q23H8-225 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the YCD6Q23H8-225?
The Yuchai YCD6Q23H8-225 is an inline-6 (6-cylinder) engine with a displacement of 7.5 L.
Is the YCD6Q23H8-225 still in production?
No — the Yuchai YCD6Q23H8-225 is discontinued. Its specifications and datasheets remain archived here for reference.
