Yunnei
Yunnei DEF30CCB5
DEF30 Series
The Yunnei DEF30CCB5 is a 3-litre inline-4 diesel engine for generator sets, rated at 45 kVA / 36 kWe prime power at 1,800 RPM (60 Hz). It is a liquid-cooled engine built in China. It meets Euro Stage V emissions standards.
Get help with this engine
Tell Haifeng whether you already own a Yunnei DEF30CCB5 engine/generator or need to source this model for a project.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-05-27
- Package route
- diesel generator sets
- Prime Power · 60 Hz
- 45 kVA
- Electrical Output
- 36 kWe
- Cylinders
- L4
- Displacement
- 3 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 40 | 36 | 45 |
Yunnei DEF30CCB5 generator set context
The Yunnei DEF30CCB5 is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 45 kVA / 36 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Yunnei |
| Model | DEF30CCB5 |
| Series | DEF30 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Yunnei DEF30CCB5?
The Yunnei DEF30CCB5 is rated at 45 kVA prime at 60 Hz (1,800 rpm).
Does the DEF30CCB5 run at 50 Hz or 60 Hz?
The Yunnei DEF30CCB5 is rated for 60 Hz (1,800 rpm).
What fuel does the Yunnei DEF30CCB5 use?
The Yunnei DEF30CCB5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DEF30CCB5?
The Yunnei DEF30CCB5 is an inline-4 (4-cylinder) engine with a displacement of 3 L.
What emissions standard does the DEF30CCB5 meet?
The Yunnei DEF30CCB5 is certified to Euro Stage V emissions standards.
Is the Yunnei DEF30CCB5 still in production?
Yes — the Yunnei DEF30CCB5 is a current production model.
Is a datasheet available for the DEF30CCB5?
Yes — an official Yunnei datasheet for the Yunnei DEF30CCB5 can be downloaded from this page.
