Baudouin
Baudouin 16M33G0D3/5
16M33
Baudouin 16M33G0D3/5 generator-drive diesel engine discovered in the GenProBase public selector. GenProBase lists 1 row(s) across 50Hz with 52.3 L displacement, 16V cylinders, liquid-cooled cooling, and China III emissions labeling. Treat this row as source-discovered and prioritize OEM datasheet attachment in a follow-up pass.
Chat on WhatsApp about this engine
Opens WhatsApp with Baudouin 16M33G0D3/5 and this page link filled in.
- Manufacturer files
- No datasheet
- Last updated
- 2026-08-05
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,750 kVA
- Electrical Output
- 1,400 kWe
- Cylinders
- V16
- Displacement
- 52.3 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1390 | 1250 | — |
| Standby Power | 1530 | 1400 | — |
Baudouin 16M33G0D3/5 generator set context
The Baudouin 16M33G0D3/5 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 1,750 kVA / 1,400 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Baudouin |
| Model | 16M33G0D3/5 |
| Series | 16M33 |
| Configuration | L16, turbocharged aftercooled |
| Cylinders | 16 |
| Displacement | 52.3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China III |
| Certifications | China III |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Baudouin 16M33G0D3/5?
The Baudouin 16M33G0D3/5 is rated at 1,750 kVA standby / 1,563 kVA prime at 50 Hz (1,500 rpm).
Does the 16M33G0D3/5 run at 50 Hz or 60 Hz?
The Baudouin 16M33G0D3/5 is rated for 50 Hz (1,500 rpm).
What fuel does the Baudouin 16M33G0D3/5 use?
The Baudouin 16M33G0D3/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 16M33G0D3/5?
The Baudouin 16M33G0D3/5 is a V16 (16-cylinder) engine with a displacement of 52.3 L.
What emissions standard does the 16M33G0D3/5 meet?
The Baudouin 16M33G0D3/5 is certified to China III emissions standards.
Is the Baudouin 16M33G0D3/5 still in production?
Yes — the Baudouin 16M33G0D3/5 is a current production model.
