Baudouin
Baudouin 16M33G6D2/5
The Baudouin 16M33G6D2/5 is a 52.8-litre V16 diesel engine for generator sets, rated at 1,900 kVA / 1,520 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in France. It meets U.S. EPA Tier 2 emissions standards.
- Standby Power · 50 Hz
- 1,900 kVA
- Electrical Output
- 1,520 kWe
- Cylinders
- V16
- Displacement
- 52.8 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1530 | 1400 | 1750 |
| Standby Power | 1680 | 1520 | 1900 |
Baudouin 16M33G6D2/5 generator set context
The Baudouin 16M33G6D2/5 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 1,900 kVA / 1,520 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Baudouin |
| Model | 16M33G6D2/5 |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 52.8 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 16M33G6D2/5?
The Baudouin 16M33G6D2/5 is rated at 1,900 kVA standby / 1,750 kVA prime at 50 Hz (1,500 rpm).
Does the 16M33G6D2/5 run at 50 Hz or 60 Hz?
The Baudouin 16M33G6D2/5 is rated for 50 Hz (1,500 rpm).
What fuel does the Baudouin 16M33G6D2/5 use?
The Baudouin 16M33G6D2/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 16M33G6D2/5?
The Baudouin 16M33G6D2/5 is a V16 (16-cylinder) engine with a displacement of 52.8 L.
What emissions standard does the 16M33G6D2/5 meet?
The Baudouin 16M33G6D2/5 is certified to U.S. EPA Tier 2 emissions standards.
Is the Baudouin 16M33G6D2/5 still in production?
Yes — the Baudouin 16M33G6D2/5 is a current production model.
Is a datasheet available for the 16M33G6D2/5?
Yes — an official Baudouin datasheet for the Baudouin 16M33G6D2/5 can be downloaded from this page.
