Baudouin
Baudouin 16M55G3300/5
The Baudouin 16M55G3300/5 is a V16 diesel engine for generator sets, rated at 3,313 kVA / 2,650 kWe standby power at 1,500 RPM (50 Hz). It is liquid-cooled.
- Standby Power · 50 Hz
- 3,313 kVA
- Electrical Output
- 2,650 kWe
- Cylinders
- V16
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2646 | 2400 | 3000 |
| Standby Power | 2900 | 2650 | 3313 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 3300 | 3000 | 3750 |
| Standby Power | 3600 | 3300 | 4125 |
Technical Specifications
| Brand | Baudouin |
| Model | 16M55G3300/5 |
| Configuration | V16 |
| Cylinders | 16 |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
