Baudouin
Baudouin 20M33G2250/5
The Baudouin 20M33G2250/5 is a 66-litre V20 diesel engine for generator sets, rated at 2,250 kVA / 1,800 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in France.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-08
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 2,250 kVA
- Electrical Output
- 1,800 kWe
- Cylinders
- V20
- Displacement
- 66 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1850 | 1600 | 2000 |
| Standby Power | 2020 | 1800 | 2250 |
Ask about Baudouin 20M33G2250/5
Choose parts / service or sourcing. Your message includes this model and page link.
Baudouin 20M33G2250/5 overhaul & repair parts
Already running a Baudouin 20M33G2250/5? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 20M33G2250/5 and your selected categories included. Attach your photos there.
Baudouin 20M33G2250/5 generator set context
The Baudouin 20M33G2250/5 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 2,250 kVA / 1,800 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Baudouin |
| Model | 20M33G2250/5 |
| Configuration | V20 |
| Cylinders | 20 |
| Displacement | 66 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 20M33G2250/5?
The Baudouin 20M33G2250/5 is rated at 2,250 kVA standby / 2,000 kVA prime at 50 Hz (1,500 rpm).
Does the 20M33G2250/5 run at 50 Hz or 60 Hz?
The Baudouin 20M33G2250/5 is rated for 50 Hz (1,500 rpm).
What fuel does the Baudouin 20M33G2250/5 use?
The Baudouin 20M33G2250/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 20M33G2250/5?
The Baudouin 20M33G2250/5 is a V20 (20-cylinder) engine with a displacement of 66 L.
What is the catalog status of the Baudouin 20M33G2250/5?
The Baudouin 20M33G2250/5 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 20M33G2250/5?
This page links reference documents for the Baudouin 20M33G2250/5. Check each document's title, model coverage, revision and rating conditions before using it for selection.
