Baudouin
Baudouin 20M33G2D2/5
The Baudouin 20M33G2D2/5 is a 66-litre V20 diesel engine for generator sets, rated at 2,250 kVA / 1,800 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in France. It meets U.S. EPA Tier 2 emissions standards.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-06-08
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 2,250 kVA
- Electrical Output
- 1,800 kWe
- Cylinders
- V20
- Displacement
- 66 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1850 | 1600 | 2000 |
| Standby Power | 2020 | 1800 | 2250 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1800 | 1600 | 2000 |
| Standby Power | 2027 | 1800 | 2250 |
Ask about Baudouin 20M33G2D2/5
Choose parts / service or sourcing. Your message includes this model and page link.
Baudouin 20M33G2D2/5 overhaul & repair parts
Already running a Baudouin 20M33G2D2/5? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 20M33G2D2/5 and your selected categories included. Attach your photos there.
Baudouin 20M33G2D2/5 generator set context
The Baudouin 20M33G2D2/5 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 2,250 kVA / 1,800 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Baudouin |
| Model | 20M33G2D2/5 |
| Configuration | V20 |
| Cylinders | 20 |
| Displacement | 66 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 20M33G2D2/5?
The Baudouin 20M33G2D2/5 is rated at 2,250 kVA standby / 2,000 kVA prime at 50 Hz (1,500 rpm); and 2,250 kVA standby / 2,000 kVA prime at 60 Hz (1,800 rpm).
Does the 20M33G2D2/5 run at 50 Hz or 60 Hz?
The Baudouin 20M33G2D2/5 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Baudouin 20M33G2D2/5 use?
The Baudouin 20M33G2D2/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 20M33G2D2/5?
The Baudouin 20M33G2D2/5 is a V20 (20-cylinder) engine with a displacement of 66 L.
What emissions information is listed for the 20M33G2D2/5?
This record lists U.S. EPA Tier 2 for the Baudouin 20M33G2D2/5. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Baudouin 20M33G2D2/5?
The Baudouin 20M33G2D2/5 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 20M33G2D2/5?
This page links reference documents for the Baudouin 20M33G2D2/5. Check each document's title, model coverage, revision and rating conditions before using it for selection.
