Baudouin
Baudouin 20M33G2D2/6
20M33
Baudouin 20M33G2D2/6 generator-drive diesel engine discovered in the GenProBase public selector. GenProBase lists 1 row(s) across 60Hz with 65.4 L displacement, 20V cylinders, liquid-cooled cooling, and U.S. EPA Tier 2 emissions labeling. Treat this row as source-discovered and prioritize OEM datasheet attachment in a follow-up pass.
Chat on WhatsApp about this engine
Opens WhatsApp with Baudouin 20M33G2D2/6 and this page link filled in.
- Manufacturer files
- No datasheet
- Last updated
- 2026-08-05
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 2,250 kVA
- Electrical Output
- 1,800 kWe
- Cylinders
- V20
- Displacement
- 65.4 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1800 | 1600 | — |
| Standby Power | 2027 | 1800 | — |
Baudouin 20M33G2D2/6 generator set context
The Baudouin 20M33G2D2/6 is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 2,250 kVA / 1,800 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Baudouin |
| Model | 20M33G2D2/6 |
| Series | 20M33 |
| Configuration | L20, turbocharged aftercooled |
| Cylinders | 20 |
| Displacement | 65.4 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Certifications | U.S. EPA Tier 2 |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Baudouin 20M33G2D2/6?
The Baudouin 20M33G2D2/6 is rated at 2,250 kVA standby / 2,000 kVA prime at 60 Hz (1,800 rpm).
Does the 20M33G2D2/6 run at 50 Hz or 60 Hz?
The Baudouin 20M33G2D2/6 is rated for 60 Hz (1,800 rpm).
What fuel does the Baudouin 20M33G2D2/6 use?
The Baudouin 20M33G2D2/6 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 20M33G2D2/6?
The Baudouin 20M33G2D2/6 is a V20 (20-cylinder) engine with a displacement of 65.4 L.
What emissions standard does the 20M33G2D2/6 meet?
The Baudouin 20M33G2D2/6 is certified to U.S. EPA Tier 2 emissions standards.
Is the Baudouin 20M33G2D2/6 still in production?
Yes — the Baudouin 20M33G2D2/6 is a current production model.
