Baudouin 4M06G20/5
The Baudouin 4M06G20/5 is a 2.4-litre inline-4 diesel engine for generator sets, rated at 18 kVA / 14 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in France.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-06-08
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 18 kVA
- Electrical Output
- 14 kWe
- Cylinders
- L4
- Displacement
- 2.4 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 18 | 12 | 15 |
| Standby Power | 20 | 14 | 18 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 23 | 15 | 19 |
| Standby Power | 25 | 16 | 20 |
Ask about Baudouin 4M06G20/5
Choose parts / service or sourcing. Your message includes this model and page link.
Baudouin 4M06G20/5 overhaul & repair parts
Already running a Baudouin 4M06G20/5? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 4M06G20/5 and your selected categories included. Attach your photos there.
Baudouin 4M06G20/5 generator set context
The Baudouin 4M06G20/5 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 18 kVA / 14 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Baudouin |
| Model | 4M06G20/5 |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 2.4 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 4M06G20/5?
The Baudouin 4M06G20/5 is rated at 18 kVA standby / 15 kVA prime at 50 Hz (1,500 rpm); and 20 kVA standby / 19 kVA prime at 60 Hz (1,800 rpm).
Does the 4M06G20/5 run at 50 Hz or 60 Hz?
The Baudouin 4M06G20/5 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Baudouin 4M06G20/5 use?
The Baudouin 4M06G20/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4M06G20/5?
The Baudouin 4M06G20/5 is an inline-4 (4-cylinder) engine with a displacement of 2.4 L.
What is the catalog status of the Baudouin 4M06G20/5?
The Baudouin 4M06G20/5 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 4M06G20/5?
This page links reference documents for the Baudouin 4M06G20/5. Check each document's title, model coverage, revision and rating conditions before using it for selection.
