Baudouin
Baudouin 4M08G5D4/5
Baudouin 4M08G5D4/5. Source: DPK-TDS-EN-4M08-7002_4M08G5D4-5_NonRad_Datasheet_26-02-05.pdf, p.1. Gross engine mechanical PRP 30 kW / ESP 33 kW at 1500 rpm. Net power is configuration-dependent and separate from gross mechanical output; no electrical genset output inferred. Emissions statement as printed: China Non-road IV; no additional certification inferred. Production status is unknown; discontinued is the user-authorized catalogue classification, not manufacturer-confirmed cessation. No production-end year asserted. Physical specifications added from manufacturer datasheets, 2026-10-21: compression ratio 17.2:1; dry engine weight 280 kg without radiator and radiator pipes; overall dimensions without radiator (L × W × H) 978 × 634 × 878 mm. Sources: DPK-TDS-EN-4M08-7002_4M08G5D4-5_NonRad_Datasheet_26-02-05.pdf (physical data on pp.1–2). Existing populated specification fields were not overwritten. Weight is dry engine weight, not genset shipping weight.
Need parts or a replacement for 4M08G5D4/5?
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-10-21
- Package route
- diesel generator sets
- Mechanical Output
- 33 kW
- Cylinders
- L4
- Displacement
- 3.17 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 30 | — | — |
| Standby Power | 33 | — | — |
Estimated rating: 29.7 kWe (33 kW × 0.90) · 50 Hz · standby
Estimated rating: 27 kWe (30 kW × 0.90) · 50 Hz · prime
Planning estimate, not a manufacturer generator rating. Confirm the alternator, engine speed and operating conditions.
Baudouin 4M08G5D4/5 overhaul & repair parts
Need help identifying a part for your 4M08G5D4/5?
Share your nameplate, parts list and destination for a quote.
Identify my part on WhatsAppAvailability and earliest dispatch confirmed for your enquiry.
Opens WhatsApp. Attach photos in the chat.
What to send for a fitment check
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Illustrations only — not a model-specific kit or stock confirmation.
View 4M08G5D4/5 spec image
Baudouin 4M08G5D4/5 generator set context
The Baudouin 4M08G5D4/5 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 33 kW / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Model name formats
Technical Specifications
| Brand | Baudouin |
| Model | 4M08G5D4/5 |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3.17 L |
| Compression Ratio | 17.2:1 |
| Dry Weight | 280 kg |
| Dimensions (L×W×H) | 978 × 634 × 878 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China Non-road IV |
Frequently asked questions
Does the 4M08G5D4/5 run at 50 Hz or 60 Hz?
The Baudouin 4M08G5D4/5 is rated for 50 Hz (1,500 rpm).
What fuel does the Baudouin 4M08G5D4/5 use?
The Baudouin 4M08G5D4/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4M08G5D4/5?
The Baudouin 4M08G5D4/5 is an inline-4 (4-cylinder) engine with a displacement of 3.17 L.
What emissions information is listed for the 4M08G5D4/5?
This record lists China Non-road IV for the Baudouin 4M08G5D4/5. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
Is the 4M08G5D4/5 still in production?
No — the Baudouin 4M08G5D4/5 is discontinued. Its specifications and datasheets remain archived here for reference.
Are reference documents available for the 4M08G5D4/5?
This page links reference documents for the Baudouin 4M08G5D4/5. Check each document's title, model coverage, revision and rating conditions before using it for selection.
