Baudouin
Baudouin 6M11G176/6
The Baudouin 6M11G176/6 is a 6.6-litre inline-6 diesel engine for generator sets, rated at 220 kVA / 176 kWe standby power at 1,800 RPM (60 Hz). It is a liquid-cooled engine built in France.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-08
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 220 kVA
- Electrical Output
- 176 kWe
- Cylinders
- L6
- Displacement
- 6.6 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 182 | 160 | 200 |
| Standby Power | 200 | 176 | 220 |
Ask about Baudouin 6M11G176/6
Choose parts / service or sourcing. Your message includes this model and page link.
Baudouin 6M11G176/6 overhaul & repair parts
Already running a Baudouin 6M11G176/6? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 6M11G176/6 and your selected categories included. Attach your photos there.
Baudouin 6M11G176/6 generator set context
The Baudouin 6M11G176/6 is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 220 kVA / 176 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Baudouin |
| Model | 6M11G176/6 |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 6.6 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 6M11G176/6?
The Baudouin 6M11G176/6 is rated at 220 kVA standby / 200 kVA prime at 60 Hz (1,800 rpm).
Does the 6M11G176/6 run at 50 Hz or 60 Hz?
The Baudouin 6M11G176/6 is rated for 60 Hz (1,800 rpm).
What fuel does the Baudouin 6M11G176/6 use?
The Baudouin 6M11G176/6 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 6M11G176/6?
The Baudouin 6M11G176/6 is an inline-6 (6-cylinder) engine with a displacement of 6.6 L.
What is the catalog status of the Baudouin 6M11G176/6?
The Baudouin 6M11G176/6 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 6M11G176/6?
This page links reference documents for the Baudouin 6M11G176/6. Check each document's title, model coverage, revision and rating conditions before using it for selection.
