Baudouin
Baudouin 6M12G2D3/5
The Baudouin 6M12G2D3/5 is a inline-6 diesel engine for generator sets, rated at 200 kVA / 160 kWe standby power at 1,500 RPM (50 Hz). It is liquid-cooled. It meets Euro Stage IIIA emissions standards.
- Standby Power · 50 Hz
- 200 kVA
- Electrical Output
- 160 kWe
- Cylinders
- L6
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 168 | 150 | 188 |
| Standby Power | 185 | 160 | 200 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 182 | 150 | 188 |
| Standby Power | 200 | 180 | 225 |
Technical Specifications
| Brand | Baudouin |
| Model | 6M12G2D3/5 |
| Configuration | L6 |
| Cylinders | 6 |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage IIIA |
