Baudouin
Baudouin 6M13G8D5/S
The Baudouin 6M13G8D5/S is a inline-6 diesel engine for generator sets, rated at 275 kVA / 220 kWe standby power at 1,500 RPM (50 Hz). It is liquid-cooled. It meets Euro Stage V emissions standards.
- Standby Power · 50 Hz
- 275 kVA
- Electrical Output
- 220 kWe
- Cylinders
- L6
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 235 | 200 | 250 |
| Standby Power | 264 | 220 | 275 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 235 | 200 | 250 |
| Standby Power | 259 | 220 | 275 |
Technical Specifications
| Brand | Baudouin |
| Model | 6M13G8D5/S |
| Configuration | L6 |
| Cylinders | 6 |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
