Baudouin 6M16G250/5
6M16 Series
The Baudouin 6M16G250/5 is a 9.6-litre inline-6 diesel engine for generator sets, rated at 250 kVA / 200 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in France.
- Standby Power · 50 Hz
- 250 kVA
- Electrical Output
- 200 kWe
- Cylinders
- L6
- Displacement
- 9.6 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 216 | 184 | 230 |
| Standby Power | 238 | 200 | 250 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 262 | 227 | 284 |
| Standby Power | 288 | 250 | 313 |
Technical Specifications
| Brand | Baudouin |
| Model | 6M16G250/5 |
| Series | 6M16 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 9.6 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 6M16G250/5?
The Baudouin 6M16G250/5 is rated at 250 kVA standby / 230 kVA prime at 50 Hz (1,500 rpm); and 313 kVA standby / 284 kVA prime at 60 Hz (1,800 rpm).
Does the 6M16G250/5 run at 50 Hz or 60 Hz?
The Baudouin 6M16G250/5 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Baudouin 6M16G250/5 use?
The Baudouin 6M16G250/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 6M16G250/5?
The Baudouin 6M16G250/5 is an inline-6 (6-cylinder) engine with a displacement of 9.6 L.
Is the Baudouin 6M16G250/5 still in production?
Yes — the Baudouin 6M16G250/5 is a current production model.
Is a datasheet available for the 6M16G250/5?
Yes — an official Baudouin datasheet for the Baudouin 6M16G250/5 can be downloaded from this page.
