Baudouin
Baudouin 6M16G220/5
6M16 Series
The Baudouin 6M16G220/5 is a 9.6-litre inline-6 diesel engine for generator sets, rated at 220 kVA / 176 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in France.
- Standby Power · 50 Hz
- 220 kVA
- Electrical Output
- 176 kWe
- Cylinders
- L6
- Displacement
- 9.6 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 187 | 160 | 200 |
| Standby Power | 204 | 176 | 220 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 240 | 200 | 250 |
| Standby Power | 264 | 220 | 275 |
Technical Specifications
| Brand | Baudouin |
| Model | 6M16G220/5 |
| Series | 6M16 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 9.6 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 6M16G220/5?
The Baudouin 6M16G220/5 is rated at 220 kVA standby / 200 kVA prime at 50 Hz (1,500 rpm); and 275 kVA standby / 250 kVA prime at 60 Hz (1,800 rpm).
Does the 6M16G220/5 run at 50 Hz or 60 Hz?
The Baudouin 6M16G220/5 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Baudouin 6M16G220/5 use?
The Baudouin 6M16G220/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 6M16G220/5?
The Baudouin 6M16G220/5 is an inline-6 (6-cylinder) engine with a displacement of 9.6 L.
Is the Baudouin 6M16G220/5 still in production?
Yes — the Baudouin 6M16G220/5 is a current production model.
Is a datasheet available for the 6M16G220/5?
Yes — an official Baudouin datasheet for the Baudouin 6M16G220/5 can be downloaded from this page.
Related Engines
Compare Baudouin 6M16G220/5
Reference
- Canonical page
- /engines/baudouin-6m16g220-5
- Last database update
- 2026-06-07
- Manufacturer files
- 1 datasheet linked
