Baudouin
Baudouin 8M33G6D2/5
The Baudouin 8M33G6D2/5 is a 26.4-litre V8 diesel engine for generator sets, rated at 1,000 kVA / 800 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in France. It meets U.S. EPA Tier 2 emissions standards.
- Standby Power · 50 Hz
- 1,000 kVA
- Electrical Output
- 800 kWe
- Cylinders
- V8
- Displacement
- 26.4 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 800 | 700 | 875 |
| Standby Power | 895 | 800 | 1000 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 815 | 720 | 900 |
| Standby Power | 946 | 840 | 1050 |
Baudouin 8M33G6D2/5 generator set context
The Baudouin 8M33G6D2/5 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,000 kVA / 800 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Baudouin |
| Model | 8M33G6D2/5 |
| Configuration | V8 |
| Cylinders | 8 |
| Displacement | 26.4 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 8M33G6D2/5?
The Baudouin 8M33G6D2/5 is rated at 1,000 kVA standby / 875 kVA prime at 50 Hz (1,500 rpm); and 1,050 kVA standby / 900 kVA prime at 60 Hz (1,800 rpm).
Does the 8M33G6D2/5 run at 50 Hz or 60 Hz?
The Baudouin 8M33G6D2/5 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Baudouin 8M33G6D2/5 use?
The Baudouin 8M33G6D2/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 8M33G6D2/5?
The Baudouin 8M33G6D2/5 is a V8 (8-cylinder) engine with a displacement of 26.4 L.
What emissions standard does the 8M33G6D2/5 meet?
The Baudouin 8M33G6D2/5 is certified to U.S. EPA Tier 2 emissions standards.
Is the Baudouin 8M33G6D2/5 still in production?
Yes — the Baudouin 8M33G6D2/5 is a current production model.
Is a datasheet available for the 8M33G6D2/5?
Yes — an official Baudouin datasheet for the Baudouin 8M33G6D2/5 can be downloaded from this page.
