BEINEI
BEINEI F4L914
914 Series
BEINEI (北内) F4L914 from Beijing Beinei Diesel Engine Co., Ltd. (北京北内柴油机有限责任公司). The user-supplied 2026 engine lineup lists an inline 4-cylinder, four-stroke, air-cooled, naturally aspirated diesel engine with 4.314 L displacement and 102 × 132 mm bore × stroke. Published mechanical power: 41 kW at 1500 rpm; 46 kW at 1800 rpm; 50 kW at 2300 rpm. Dimensions (L × W × H): 860 × 679 × 821 mm; net weight: 310 kg. Power duty is not specified in the 2026 table; prime, standby, electrical output and emissions certification are not inferred. The attached older brochure provides manufacturer and family reference information; the 2026 table takes precedence for these specifications.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-09-18
- Package route
- diesel generator sets
- Mechanical Output
- 41 kW
- Cylinders
- L4
- Displacement
- 4.314 L
- Rated Speed
- 1,500 RPM
Ask about BEINEI F4L914
Choose parts / service or sourcing. Your message includes this model and page link.
BEINEI F4L914 overhaul & repair parts
Already running a BEINEI F4L914? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with F4L914 and your selected categories included. Attach your photos there.
BEINEI F4L914 generator set context
The BEINEI F4L914 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 41 kW / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | BEINEI |
| Model | F4L914 |
| Series | 914 Series |
| Configuration | L4, four-stroke, naturally aspirated |
| Cylinders | 4 |
| Displacement | 4.314 L |
| Dry Weight | 310 kg |
| Dimensions (L×W×H) | 860 × 679 × 821 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Air-Cooled |
| Country of Origin | China |
Frequently asked questions
What fuel does the BEINEI F4L914 use?
The BEINEI F4L914 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the F4L914?
The BEINEI F4L914 is an inline-4 (4-cylinder) engine with a displacement of 4.314 L.
What is the catalog status of the BEINEI F4L914?
The BEINEI F4L914 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the F4L914?
This page links reference documents for the BEINEI F4L914. Check each document's title, model coverage, revision and rating conditions before using it for selection.
