Caterpillar
Caterpillar 3412
3400 Series
Caterpillar 3412 27L 12-cylinder diesel engine for generator sets. 800 ekW standby at 60Hz. U.S. EPA Tier 2. Turbocharged Aftercooled.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-28
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 800 kVA
- Electrical Output
- 640 kWe
- Cylinders
- V12
- Displacement
- 27 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 644.4 | 580 | 725 |
| Standby Power | 711.1 | 640 | 800 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 807.8 | 727 | 908.8 |
| Standby Power | 888.9 | 800 | 1000 |
Ask about Caterpillar 3412
Choose parts / service or sourcing. Your message includes this model and page link.
Caterpillar 3412 overhaul & repair parts
Already running a Caterpillar 3412? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 3412 and your selected categories included. Attach your photos there.
Caterpillar 3412 generator set context
The Caterpillar 3412 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 800 kVA / 640 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Caterpillar |
| Model | 3412 |
| Series | 3400 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 27 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the Caterpillar 3412?
The Caterpillar 3412 is rated at 800 kVA standby / 725 kVA prime at 50 Hz (1,500 rpm); and 1,000 kVA standby / 909 kVA prime at 60 Hz (1,800 rpm).
Does the 3412 run at 50 Hz or 60 Hz?
The Caterpillar 3412 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Caterpillar 3412 use?
The Caterpillar 3412 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 3412?
The Caterpillar 3412 is a V12 (12-cylinder) engine with a displacement of 27 L.
What emissions information is listed for the 3412?
This record lists U.S. EPA Tier 2 for the Caterpillar 3412. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Caterpillar 3412?
The Caterpillar 3412 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 3412?
This page links reference documents for the Caterpillar 3412. Check each document's title, model coverage, revision and rating conditions before using it for selection.
