Caterpillar
Caterpillar 3616
3600 Series
Caterpillar 3616 — 295.5 L V16 turbocharged-aftercooled diesel generator engine (Cat 3600 series). 5720 ekW standby / 5200 ekW prime @ 50 Hz, 5320 / 4840 ekW @ 60 Hz; medium-speed V16 (280×300 mm); marketed as C280-16 (IMO/EPA Tier 2) marine. Source: Cat 2024 Electric Power Ratings Guide.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-06-11
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 7,150 kVA
- Electrical Output
- 5,720 kWe
- Cylinders
- V16
- Displacement
- 295.5 L
- Rated Speed
- 1,000 / 1,200 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 5200 | 6500 |
| Standby Power | — | 5720 | 7150 |
60 Hz1200 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 4840 | 6050 |
| Standby Power | — | 5320 | 6650 |
Ask about Caterpillar 3616
Choose parts / service or sourcing. Your message includes this model and page link.
Caterpillar 3616 overhaul & repair parts
Already running a Caterpillar 3616? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 3616 and your selected categories included. Attach your photos there.
Caterpillar 3616 generator set context
The Caterpillar 3616 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 7,150 kVA / 5,720 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Caterpillar |
| Model | 3616 |
| Series | 3600 Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 295.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the Caterpillar 3616?
The Caterpillar 3616 is rated at 7,150 kVA standby / 6,500 kVA prime at 50 Hz (1,000 rpm); and 6,650 kVA standby / 6,050 kVA prime at 60 Hz (1,200 rpm).
Does the 3616 run at 50 Hz or 60 Hz?
The Caterpillar 3616 is available for both 50 Hz (1,000 rpm) and 60 Hz (1,200 rpm).
What fuel does the Caterpillar 3616 use?
The Caterpillar 3616 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 3616?
The Caterpillar 3616 is a V16 (16-cylinder) engine with a displacement of 295.5 L.
What emissions information is listed for the 3616?
This record lists U.S. EPA Tier 2 for the Caterpillar 3616. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Caterpillar 3616?
The Caterpillar 3616 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 3616?
This page links reference documents for the Caterpillar 3616. Check each document's title, model coverage, revision and rating conditions before using it for selection.
