Caterpillar
Caterpillar 3606
3600 Series
Caterpillar 3606 — 110.8 L L6 turbocharged-aftercooled diesel generator engine (Cat 3600 series). 2150 ekW standby / 1940 ekW prime @ 50 Hz, 2000 / 1820 ekW @ 60 Hz; medium-speed inline-6 (280×300 mm); marketed as C280-6 (IMO/EPA Tier 2) marine. Source: Cat 2024 Electric Power Ratings Guide.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-06-11
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 2,688 kVA
- Electrical Output
- 2,150 kWe
- Cylinders
- L6
- Displacement
- 110.8 L
- Rated Speed
- 1,000 / 1,200 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1940 | 2425 |
| Standby Power | — | 2150 | 2687.5 |
60 Hz1200 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1820 | 2275 |
| Standby Power | — | 2000 | 2500 |
Ask about Caterpillar 3606
Choose parts / service or sourcing. Your message includes this model and page link.
Caterpillar 3606 overhaul & repair parts
Already running a Caterpillar 3606? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 3606 and your selected categories included. Attach your photos there.
Caterpillar 3606 generator set context
The Caterpillar 3606 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 2,688 kVA / 2,150 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Caterpillar |
| Model | 3606 |
| Series | 3600 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 110.8 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the Caterpillar 3606?
The Caterpillar 3606 is rated at 2,688 kVA standby / 2,425 kVA prime at 50 Hz (1,000 rpm); and 2,500 kVA standby / 2,275 kVA prime at 60 Hz (1,200 rpm).
Does the 3606 run at 50 Hz or 60 Hz?
The Caterpillar 3606 is available for both 50 Hz (1,000 rpm) and 60 Hz (1,200 rpm).
What fuel does the Caterpillar 3606 use?
The Caterpillar 3606 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 3606?
The Caterpillar 3606 is an inline-6 (6-cylinder) engine with a displacement of 110.8 L.
What emissions information is listed for the 3606?
This record lists U.S. EPA Tier 2 for the Caterpillar 3606. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Caterpillar 3606?
The Caterpillar 3606 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 3606?
This page links reference documents for the Caterpillar 3606. Check each document's title, model coverage, revision and rating conditions before using it for selection.
