Caterpillar
Caterpillar C175-16
C Series
Caterpillar C175-16 — 85.6 L V16 turbocharged-aftercooled diesel generator engine (Cat C-Series series). 2400 ekW standby / 2180 ekW prime @ 50 Hz, 3000 / 2725 ekW @ 60 Hz; high-speed V16 (175×220 mm); EPA Tier 4 Final / EPA Stationary Emergency. Source: Cat 2024 Electric Power Ratings Guide.
- Standby Power · 50 Hz
- 3,000 kVA
- Electrical Output
- 2,400 kWe
- Cylinders
- V16
- Displacement
- 85.6 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 2180 | 2725 |
| Standby Power | — | 2400 | 3000 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 2725 | 3406.3 |
| Standby Power | — | 3000 | 3750 |
Caterpillar C175-16 generator set context
The Caterpillar C175-16 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 3,000 kVA / 2,400 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Caterpillar |
| Model | C175-16 |
| Series | C Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 85.6 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Final Tier 4 |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the Caterpillar C175-16?
The Caterpillar C175-16 is rated at 3,000 kVA standby / 2,725 kVA prime at 50 Hz (1,500 rpm); and 3,750 kVA standby / 3,406 kVA prime at 60 Hz (1,800 rpm).
Does the C175-16 run at 50 Hz or 60 Hz?
The Caterpillar C175-16 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Caterpillar C175-16 use?
The Caterpillar C175-16 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the C175-16?
The Caterpillar C175-16 is a V16 (16-cylinder) engine with a displacement of 85.6 L.
What emissions standard does the C175-16 meet?
The Caterpillar C175-16 is certified to U.S. EPA Final Tier 4 emissions standards.
Is the Caterpillar C175-16 still in production?
Yes — the Caterpillar C175-16 is a current production model.
Is a datasheet available for the C175-16?
Yes — an official Caterpillar datasheet for the Caterpillar C175-16 can be downloaded from this page.
