Cummins
Cummins KTA38-G1B
K38 Series
The Cummins KTA38-G1B is a 38-litre V12 diesel engine for generator sets, rated at 788 kVA / 630 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Overhaul & repair parts- Supporting documents
- 2 documents · 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 788 kVA
- Electrical Output
- 630 kWe
- Cylinders
- V12
- Displacement
- 38 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 633.3 | 570 | 712.5 |
| Standby Power | 700 | 630 | 787.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 777.8 | 700 | 875 |
| Standby Power | 855.6 | 770 | 962.5 |
Ask about Cummins KTA38-G1B
Choose parts / service or sourcing. Your message includes this model and page link.
Cummins KTA38-G1B overhaul & repair parts
Already running a Cummins KTA38-G1B? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with KTA38-G1B and your selected categories included. Attach your photos there.
Cummins KTA38-G1B generator set context
The Cummins KTA38-G1B is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 788 kVA / 630 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Cummins |
| Model | KTA38-G1B |
| Series | K38 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 38 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Cummins KTA38-G1B?
The Cummins KTA38-G1B is rated at 788 kVA standby / 713 kVA prime at 50 Hz (1,500 rpm); and 963 kVA standby / 875 kVA prime at 60 Hz (1,800 rpm).
Does the KTA38-G1B run at 50 Hz or 60 Hz?
The Cummins KTA38-G1B is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Cummins KTA38-G1B use?
The Cummins KTA38-G1B is a diesel generator-set engine.
What is the displacement and cylinder configuration of the KTA38-G1B?
The Cummins KTA38-G1B is a V12 (12-cylinder) engine with a displacement of 38 L.
What is the catalog status of the Cummins KTA38-G1B?
The Cummins KTA38-G1B is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the KTA38-G1B?
This page links reference documents for the Cummins KTA38-G1B. Check each document's title, model coverage, revision and rating conditions before using it for selection.
